Rexroth A4VG Series A4VG28 A4VG40 A4VG56 A4VG71 A4VG90 A4VG125Closed Loop Piston Pump Piston Single Pump Variable Piston
Rexroth A4VG Series A4VG28 A4VG40 A4VG56 A4VG71 A4VG90 A4VG125Closed Loop Piston Pump Piston Single Pump Variable Piston
Specifications
Brand Name :
REXROTH
Model Number :
A4VG125 A4VG145 A4VG175 A4VG210 A4VG280
Place of Origin :
China
MOQ :
1PCS
Price :
NIGOTIATION
Payment Terms :
T/T
Supply Ability :
1000/month
Delivery Time :
15 work days
Packaging Details :
standard box
Usage :
Oil,Hydraulic Piston Pump
Appliion :
Hydraulic System,hydraulic pumps,exvaor
Structure :
Piston Pump,Hydraulic Pumps
Power :
Hydraulic
Pressure :
High Pressure
Fuel :
hydraulic,oil
Theory :
Rotary Pump,hydraulic pumps
Standard or nonstandard :
Standard
Color :
Customer's Request,customize
Material :
Cast Iron
Product name :
Hydraulic Pumps
Warranty :
1 Year
Condition :
100%new,OEM new & original
Feature :
High Efficiency,Long Life
Type :
Hydraulic pump Rexroth
Application :
Hydraulic System
MODEL :
A4VG series
Description

rexroth pump A4VG CHARGE A4VG45 A4VG50 A4VG56 A4VG71 A4VG125 A4VG180 300bar rexroth hydraulic a4vtg90 a4vg125hd piston pump

Rexroth A4VG Series A4VG28 A4VG40 A4VG56 A4VG71 A4VG90 A4VG125Closed Loop Piston Pump Piston Single Pump Variable Piston

Working principle of plunger pump
The piston pump is divided into two representative structural forms: axial piston pump and radial piston pump; Because radial piston pump is a new type of high-efficiency pump with high technology content, radial piston pump will become an important part of the application field of piston pump; Radial piston pump is a kind of piston pump whose reciprocating motion direction is perpendicular to the driving shaft.The oil flow in and out of the pump body and the flow passage on the valve shaft are controlled by the oil suction port on the valve shaft. The liquid pressure generated in the pump body is absorbed by the surface of static pressure balance.

Axial piston variable pump AA4VG series 32
High pressure pump for applications in closed circuits
Size 28 … 125
Nominal pressure 400 bar
Maximum pressure 450 bar
Closed circuit
SAE version (for the US market)
Features
Integrated boost pump for boost and pilot oil supply
Flow direction changes when the swashplate is moved through the neutral position
High-pressure relief valves with integrated boost function
With adjustable pressure cut-off as standard
Boost-pressure relief valve
Through drive for mounting of further pumps up to same nominal size
Large variety of controls
Swashplate design
Table of values
Size
28
40
56
71
90
125
Displacement
geometric, per revolution
Vg max
cm³
28
40
56
71
90
125
Nominal pressure
pnom
bar
400
400
400
400
400
400
Maximum pressure
pmax
bar
450
450
450
450
450
450
Maximum speed
at Vg max
nnom
rpm
4250
4000
3600
3300
3050
2850
Intermittent1)
nmax
rpm
5000
5000
4500
4100
3800
3450
Flow
at Vg max and nnom
qV nom
l/min
119
160
202
234
275
356
Power
at qV nom and Δpnom2)
P
kW
79
107
134
156
183
238
Torque
at Vg max and Δpnom
M
Nm
178
255
357
452
573
796
Weight (approx.)
m
kg
29
31
38
50
60
80

The characteristics of Eternal A4VG pump:
1. The capacity of the pump is in proportion to its rotating speed and displacement; the stepless adjustment of the displacement
can be materialized by regulating the swivel angle of its swash plate.
2. With through-shaft structure, able to form combination pump.
3. Position constraint return mechanism.
4. Spherical flow distribution, the piston is inclined around the shaft.
5. Equipped with swivel angle indicator of swash plate.
6. Stepless variable displacement.
7. Excellent suction performance.
8. Rated working pressure of 35MPa.
9. Fast control response.
10. Low noise.
11. Long lifespan.
12. Excellent power/weight ratio.
13. Modular design.
14. The drive shaft is able to bear the axial and radial load.
15. Optional installation position.
16. It can operate with HF fluid to lower the operating parameter.
17.Completely interchangeable with original
