Rexroth A11VO Hydraulic Pump A11VO95 A11VO130 A11VO190 A11VO145 A11VO75 Rexroth A11VLO130EP2D/10R-NZD12N00P
Rexroth A11VO Hydraulic Pump A11VO95 A11VO130 A11VO190 A11VO145 A11VO75 Rexroth A11VLO130EP2D/10R-NZD12N00P
Specifications
Model Number :
A11VO40, A11VO60, A11VO75, A11VO95, A11VO130, A11VO145, A11VO190,A11VO260
Fuel :
hydraulic oil
Type :
Hydraulic Motors,Hydraulic Power Units
MOQ :
1
Delivery Time :
5 work days
Application :
Excavator
Price :
NIGOTIATION
Color :
Black,customized color
Payment Terms :
T/T,T/T
Appliion :
Crawler Excavator,Bulldozer,Crawler Undercarriage,For excavator,Excavator Undercarriage Parts
Usage :
Oil
After-sales service provided :
Online support,Video technical support
Pressure :
High Pressure
Certification :
CE ISO 9001
Brand Name :
REXROTH
Power :
Hydraulic
Packaging Details :
standard
Supply Ability :
1000/month
Warranty :
1 Year
Place of Origin :
China
Structure :
Hydraulic piston pump
Theory :
Rotary Pump,plunger pump
Material :
Cast Iron
Standard or nonstandard :
Standard
Description


Rexroth A11VO Hydraulic Pump A11VO95 A11VO130 A11VO190 A11VO145 A11VO75 Rexroth A11VLO130EP2D/10R-NZD12N00P

PRODUCT OVERVIEW

* All-purpose high pressure pump with through drive
* Size 40 … 260
* Nominal pressure 350 bar
* Maximum pressure 400 bar
* Open circuit
* Metric version
* All-purpose high pressure pump with through drive
* Open circuit
* Through drive for mounting of further pumps up to same nominal size
* Optional with charge pump for the nominal sizes 130…260
* Particularly high speeds are possible with impeller pump version (A11VLO)
* Large variety of controls
* Swashplate design

Product Series
A11VLO Axial Piston Variable Pump
Working Circuit
Open Circuit
Structure Type
Swash Plate Axial Piston Type
Rated Working Pressure
350 Bar (35 MPa)
Maximum Peak Pressure
400 Bar (40 MPa)
Displacement Range
40~260 ml/r (Full series specification)
Displacement Adjustment
0–100% Stepless Variable
Standard Control Modes
DR, LR, HD, EP
Operating Speed Range
600–2200 r/min (Depends on displacement)
Suction Pressure (Charge Pump Version)
0.6–2.0 Bar Absolute Pressure
Operating Temperature Range
-20℃ ~ +95℃
Recommended Hydraulic Oil
HLP Anti-wear Hydraulic Oil (DIN 51524)
Applicable Oil Viscosity
20–45 mm²/s
Volumetric Efficiency
≥ 94%
Comprehensive Efficiency
≥ 88%

Table of values

Size 40 60 75 95 130 145 190 260 130 145 190 260
Version Standard With charge pump
Displacement
geometric, per revolution		 Vg max cm³ 42 58.5 74 93.5 130 145 193 260 130 145 193 260
Nominal pressure pnom bar 350 350 350 350 350 350 350 350 350 350 350 350
Maximum pressure pmax bar 400 400 400 400 400 400 400 400 400 400 400 400
Maximum speed at Vg max nnom rpm 3000 1) 2700 1) 2550 1) 2350 1) 2100 1) 2200 1) 2100 1) 1800 1) 2500 2) 2500 2) 2500 2) 2300 2)
Flow at Vg max and nnom qV nom l/min 126 158 189 220 273 319 405 468 325 363 483 598
Power at qV nom and pnom P kW 74 92 110 128 159 186 236 273 190 211 281 349
Torque at Vg max and pnom M Nm 234 326 412 521 724 808 1075 1448 724 808 1075 1448
Weight (approx.) m kg 32 40 45 53 66 76 95 125 72 73 104 138

APPLICATION FIELDS

A11VLO series hydraulic pumps are widely used in heavy-duty mobile machinery and industrial hydraulic systems, including concrete pump trucks, excavators, loaders, road construction machinery, mining equipment, port handling machinery, large hydraulic stations and automated heavy-duty production lines. It provides stable, energy-saving and precise hydraulic power for high-load, long-duration and variable-load operating equipment, effectively improving equipment operating efficiency and operational stability.
Rexroth A11VO Hydraulic Pump A11VO95 A11VO130 A11VO190 A11VO145 A11VO75 Rexroth A11VLO130EP2D/10R-NZD12N00P

MAIN MODEL SPECIFICATIONS

The A11VLO series covers full displacement specifications for diversified application matching: A11VLO40, A11VLO60, A11VLO75, A11VLO95, A11VLO130, A11VLO145, A11VLO190, A11VLO260. Each model supports customized control modes, rotation directions and sealing configurations to meet different equipment power and control requirements.
A11VO145LRDS/11R-NZD12N00
A11VLO145EP2D/11L-NZD12K04P
A11VLO145DRS/11R-NSD12K02
A11VLO190LE2S/11L-NZD12K81P
A11VLO190LRDU2/11R-NZD12K02P-S
A11VLO190LRDS/11R-NSD12K01
