Heavy-Duty Pile Driver for 21m Deep Foundation Projects
Heavy-Duty Pile Driver for 21m Deep Foundation Projects
Heavy-Duty Pile Driver for 21m Deep Foundation Projects
Heavy-Duty Pile Driver for 21m Deep Foundation Projects
Heavy-Duty Pile Driver for 21m Deep Foundation Projects
Heavy-Duty Pile Driver for 21m Deep Foundation Projects
Heavy-Duty Pile Driver for 21m Deep Foundation Projects
Heavy-Duty Pile Driver for 21m Deep Foundation Projects
Heavy-Duty Pile Driver for 21m Deep Foundation Projects
Heavy-Duty Pile Driver for 21m Deep Foundation Projects
Specifications
Brand Name :
VIBRA
Model Number :
PCF-500
Certification :
ISO 9001:2015
Place of Origin :
Shanghai, China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
15 set/month
Delivery Time :
7-35 days
Packaging Details :
8.6 CBM
Name :
Hydraulic Pile Driving Machine
Operation Pressure :
30Mpa
Arm Weight :
820 kg
Hammer Weight :
3600kg
Vibration Frequency :
3200rpm
Condition :
New
Centrifugal Force :
828 Kn
Excavator :
60~68 ton
Eccentric moment :
9.2 kgm
Maximum piling depth :
21 meter
HS Code :
8430100000
Color :
Blue/Yellow/Red/White, customized color available
Description
Heavy-Duty Pile Driver for 21m Deep Foundation Projects
Product Description

Meet the PCF-500, a high-performance hydraulic pile driver engineered for large-scale projects. It delivers an impressive 828kN of exciting force to handle 21-meter sheet piles, steel guard cylinders, and PC piles with maximum efficiency. Designed for reliability and power, this pile driver is your ideal partner for demanding foundation work.

Core Keywords
  • Pile Driver
  • Sheet Pile Driver
  • Hydraulic Pile Driver
  • Vibro Hammer
  • Heavy Duty Pile Driver
  • Foundation Equipment
  • PCF-500
Key Features & Advantages
  • Unmatched Power: Generates a massive 828kN Exciting Force to drive piles deep into the ground for the most demanding large-scale construction projects.
  • Extended Reach: Capable of handling piling depths up to 21 meters, making it perfect for large steel sheet piles and protective cylinders.
  • Superior Reliability: Features a robust cast steel chuck and a 160 cylinder, delivering a powerful 602KN clamping force for secure and stable piling operations.
  • Advanced Engineering: Equipped with a new electronic control system and a large-flow confluence valve (700L) to prolong component life and enhance performance.
  • Premium Components: Built with core stability in mind, utilizing an imported Parker motor, Swedish SKF bearings, and a box bearing self-lubricating system.
Technical Parameters
Parameter Value
Model PCF-500
Exciting Force 828 kN
Maximum Piling Depth 21 m
Hammer Head Weight 3600 kg
Eccentric Moment 9.2 kgm
Recommended Excavator 60~68 T
Frequently Asked Questions (FAQ)

Q: What type of piles is this pile driver suitable for?

A: It is specifically designed for driving large steel sheet piles, steel guard cylinders, and PC mixed piles up to 21 meters in length.

Q: What excavator size is required to operate the PCF-500?

A: This model is designed to be matched with excavators in the 60 to 68-ton weight class for optimal performance.

Q: What makes your pile drivers more reliable?

A: Our pile drivers are built with super-strength structural parts, a self-lubricating bearing system, and premium imported components like Parker motors and SKF bearings to ensure core stability and a long service life.

Q: Are you a manufacturer?

A: Yes, we are Ye Kun Construction Machinery Co., Ltd., a technology-oriented enterprise specializing in the production and development of high-quality piling equipment under the VIBRA brand.

Q: Can the pile driver be customized for specific projects?

A: We focus on developing specialized, large-scale equipment. Please contact our team directly to discuss your specific project requirements.
