D4G D5G Small Dozer Bulldozer Hydraulic Piston Motor 169-2976 1692976 Construction Machinery GP-PISTON Parts
D4G D5G Small Dozer Bulldozer Hydraulic Piston Motor 169-2976 1692976 Construction Machinery GP-PISTON Parts
D4G D5G Small Dozer Bulldozer Hydraulic Piston Motor 169-2976 1692976 Construction Machinery GP-PISTON Parts
D4G D5G Small Dozer Bulldozer Hydraulic Piston Motor 169-2976 1692976 Construction Machinery GP-PISTON Parts
D4G D5G Small Dozer Bulldozer Hydraulic Piston Motor 169-2976 1692976 Construction Machinery GP-PISTON Parts
D4G D5G Small Dozer Bulldozer Hydraulic Piston Motor 169-2976 1692976 Construction Machinery GP-PISTON Parts
D4G D5G Small Dozer Bulldozer Hydraulic Piston Motor 169-2976 1692976 Construction Machinery GP-PISTON Parts
D4G D5G Small Dozer Bulldozer Hydraulic Piston Motor 169-2976 1692976 Construction Machinery GP-PISTON Parts
D4G D5G Small Dozer Bulldozer Hydraulic Piston Motor 169-2976 1692976 Construction Machinery GP-PISTON Parts
D4G D5G Small Dozer Bulldozer Hydraulic Piston Motor 169-2976 1692976 Construction Machinery GP-PISTON Parts
Specifications
Payment Terms :
T/T,Paypal and Trade Assurance
Name :
Hydraulic pump
Type :
PSVD2-18E-3
Place of Origin :
Japan
Model Number :
O&k RH1.35
Condition :
New
MOQ :
1 piece
Delivery Time :
1-7days
Shipment :
Sea Air Express
Price :
Negotiable price
Application :
Excavator
Certification :
ISO9001 / 2006/42/EC
Supply Ability :
1000pieces
Model :
O&k RH1.35
Part number :
B0600-21055
Brand Name :
Belparts
Power :
Hydraulic
Packaging Details :
Wooden packing
Description
1. Basic Info

Product Name: GP‑PISTON Hydraulic Piston Motor
OEM Part Number: 169‑2976, 1692976
Fit Machine: CAT D4G, D5G Small Crawler Bulldozer
Product Type: Fixed‑displacement axial piston hydraulic motor
Condition: Aftermarket new construction machinery spare part

D4G D5G Small Dozer Bulldozer Hydraulic Piston Motor 169-2976 1692976 Construction Machinery GP-PISTON Parts
2. Core Advantages
  • Precise dimensional replication of original 169‑2976 assembly, perfect bolt‑on replacement for CAT D4G / D5G fan drive circuit
  • High‑strength piston and cylinder barrel components, stable output under continuous high‑temperature working environment of bulldozer engine compartment
  • Low‑friction valve‑plate design, reduces internal leakage and delivers consistent fan speed for engine heat dissipation
  • Reinforced shaft seal assembly, effectively prevents oil contamination caused by dust and debris on construction sites
  • Full‑pressure and no‑load rotation testing completed before shipment, no modification required during installation
3. Technical Data
Parameter Value
Motor Type Axial fixed‑displacement piston motor
OEM No. 169‑2976
Displacement 45 ml/r
Max Working Pressure 24.5 MPa
Continuous Operating Pressure 21 MPa
Rated Rotation Speed 0‑2800 rpm
Max Output Torque 385 N·m
Drive Shaft Straight key shaft
Main Oil Port G3/4
Drain Port G3/8
Mounting SAE 2‑bolt flange installation
Net Weight 14 KG
Application Hydraulic fan drive motor for 11‑15 Ton crawler bulldozer
4. FAQ

Q1: What function does this 169‑2976 piston motor serve on D4G and D5G?

A1: It acts as the hydraulic fan drive motor for the bulldozer cooling system.

Q2: Can this motor fit other CAT dozer models?

A2: It is specially designed for CAT D4G, D5G. Please cross‑check OEM part number before installation on other machines.

Q3: How long is the warranty period?

A3: 12‑month warranty against manufacturing defects.
