ZLP800 Suspended Cradle 800kg Rated Load Building Cleaning Equipment Swing Stage for Sale
ZLP800 Suspended Cradle 800kg Rated Load Building Cleaning Equipment Swing Stage for Sale
ZLP800 Suspended Cradle 800kg Rated Load Building Cleaning Equipment Swing Stage for Sale
ZLP800 Suspended Cradle 800kg Rated Load Building Cleaning Equipment Swing Stage for Sale
ZLP800 Suspended Cradle 800kg Rated Load Building Cleaning Equipment Swing Stage for Sale
ZLP800 Suspended Cradle 800kg Rated Load Building Cleaning Equipment Swing Stage for Sale
ZLP800 Suspended Cradle 800kg Rated Load Building Cleaning Equipment Swing Stage for Sale
ZLP800 Suspended Cradle 800kg Rated Load Building Cleaning Equipment Swing Stage for Sale
Specifications
Brand Name :
HYCM
Model Number :
ZLP800 Suspended Cradle 800kg Rated Load Building Cleaning Equipment Swing Stage for Sale
Certification :
CE, ISO
Place of Origin :
China
Rated Load :
800kg
Motor power :
2*1.8 kw
Height :
100m
Model :
ZLP800 Suspended Cradle 800kg Rated Load Building Cleaning Equipment Swing Stage for Sale
Rated speed :
9-11 m/min
Power supply :
440V/60Hz, 380V/50Hz or customized
Platform length :
6m or 7.5m
Condition :
100% new
MOQ :
1 set of suspended working platform
Price :
Negotiation
Payment Terms :
30% advance payment and balance before shipment or by copy of B/L OR 100%LC at sight
Supply Ability :
300 pcs of suspended working platform per month
Delivery Time :
7-15 days after receiving the deposit
Packaging Details :
In nude or as customized, 20'GP or 40'HQ containers for suspended working platform
Description

ZLP800 Suspended Cradle 800kg Rated Load Building Cleaning Equipment Swing Stage for Sale

Specification for ZLP800 Suspended Cradle 630kg Rated Load Building Cleaning Equipment Swing Stage for Sale

Type ZLP800 Suspended Platform
Rated load(kg) 800
Lifting speed(m/min) 8.2
Motor power(kw) 2×1.8 50HZ
Brake torque(Km) 15.2
Steel rope angle adjusting range(°) 3°- 8°
Distance between two steel rope(mm) ≤100
Rated stretch of front beam(mm) 1100-1700

Suspending Platform

 Locking Aluminum alloy
Nr. of platform rack Single rack
Nr. of platform 3
L×W×H(mm) (2500×3)×690×1180
Weight(kg) 217
Suspending mechanism(kg) 2×175 Kg
Counterweight(kg) optional 25×40pcs
Diameter of steel rope(mm) 8.6
Voltage(v) 3PHASES 380V or as per your inquiry

Features of ZLP800 Suspended Cradle 800kg Rated Load Building Cleaning Equipment Swing Stage for Sale

1.Our suspended working platform can be widely used parapet and complicated building in different height. And we can also supply customized platform to meet different requirements from customers.

2. Besides, Suspension Working Platform can be used to lift specific weight.

3.Suspension power Working Platform is a temporary, flexible high access equipment for maintenance and construction work. distinguished from permanent access equipment. It can be disassembled conveniently.

4. ZLP800 suspended platform uses LTD80 hoisting motor. It has electromagnetic brake motor, centrifugal speed limiting device, two steep speed reducer and “a” type rope winding system.

5. Suspension Working Platform is a good helper for construciton and decoration of high buildings.

6. It compared with traditional scaffolding, can save labours and time to maintain the high buildings, such as industry workshop, water tower, bridge, TV tower, big chimney, cenotaph, dam,etc.

7. Hoisting motor can wind rope automatically. Operator only need to insert rope into the motor.

FAQ for ZLP800 Suspended Cradle 800kg Rated Load Building Cleaning Equipment Swing Stage for Sale
Q1: What is the Warranty for suspended platform?
A1: For suspended platform, we can supply 0.5 year’s warranty. If any quality problems (not artificial reason) on our side occurred during this period, we will supply a free new one as replacement.
Q2: What is the meaning of ZLP for suspended platform model? And please illustrate.
A2: ZLP is classified according to China National Standard.
“Z” is the acronym of decoration machinery in Chinese language (Zhuang Xiu Ji Xie);
“L” is the second word acronym of platform in Chinese language (Diao Lan);
“P” is the acronym of climbing type in Chinese language (Pa Sheng Shi).
For example: ZLP630 means aerial suspended platform, and 630kg rated load (630 is the main specification rated load)
Q3: What are the optional parts for your suspended platform?
A3:1) Safety belt
2) Concrete counter-weight. (If you don’t need the weights, we could supply the molds for you to make them by yourself.)
Q4: What are the safety devices for your suspended platform?
A4: The safety device for suspended platform includes safety wire rope, safety lock and travel limiter.
Q5: What is process to make an order?
A5: Any inquires will receive our immediate reply (within 24 hours), by contact and communication (online contact is better) to sigh a contract. Then starting to produce and making package within 10 days after receiving the advance payment. A shipment advice will offered after shipping so that you could get the goods in time. 24 hours after-sales service will be supplied for you.
Q6: What is your trade items of suspended working platform?
Qingdao or Shanghai or according to Clients' need. We could accept 1 set of our products as your trial order.
If any question about working platform, please feel free to contact us. We are waiting for you!
Photos for ZLP800 Suspended Cradle 800kg Rated Load Building Cleaning Equipment Swing Stage for Sale
ZLP800 Suspended Cradle 800kg Rated Load Building Cleaning Equipment Swing Stage for SaleZLP800 Suspended Cradle 800kg Rated Load Building Cleaning Equipment Swing Stage for SaleZLP800 Suspended Cradle 800kg Rated Load Building Cleaning Equipment Swing Stage for Sale

ZLP800 Suspended Cradle 800kg Rated Load Building Cleaning Equipment Swing Stage for SaleZLP800 Suspended Cradle 800kg Rated Load Building Cleaning Equipment Swing Stage for Sale
