Specifications
Brand Name :
HYCM or XINGDAO
Model Number :
SC Building Hoist
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 set
Price :
$16800-19900 per set
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
40 sets per month
Delivery Time :
10 days after receiving the deposit or origin LC
Packaging Details :
Naked packing, 1*40’HQ containers.
Condition :
100% New
Application :
Buildings and projects
Type :
Electric cable climbing
Load :
500kg
Max. height :
150-250m
Rated speed :
33m/min
Power supply :
380V/50Hz or according to client's requirements
Motor power :
1*11kw
Motor brand :
Xingxiang, Shuangma,sanshang, juli or other
Mast section size :
650*650*1508mm
Description

SC50 Small Building Construction Lifts Single Elevator Cage 500kg Load

Short Introduction

1. SC50 Single Cage Constructoin Hoist

2. Rated laod: 500kg

3. Max. height: 250m

4. Speed: 33m/min

5. Cage size: 1*1.2*2.2m

6. Use rack-and-pinion transmission technology.
7. CNC Plasma/Flame Cutting Machine
8. Mast Section Robot welding line
9. Impeller Blasting

10. Baking painting

11. Full set safety device

12 Accepted customer’s OEM

Specification

Model SC50
Payload capacity Up to 500 kg
Speed 0-33 m/min
Max. lifting height 150 m (Increased lifting height on request.)
Cage width (internal) 1 m
Cage length (internal) 1.2 m
Cage height (internal) 2.2 m
Motor control Directly driven without inverter
Motor power 1 x 11 kw
Safety device Mechanical interlocking door system to guarantee the highest safety standards.
Power supply range 380V, 50Hz or 60 Hz, 3 phase
Type of mast 0.65*0.65*1.508m
Length mast section 1.508 m

Main Characteristic

1. The mast sections of construction hoist adopt welding robot to weld, reliable in price and elegant in appearance.

2. All the structures adopt reaming impeller blasting technology, the adhesion of surface painting is good.

3. The wall around cage can be fixed by Punched Aluminum plate, Punched zinc plate, steel wire mesh.

4. Professional manufacturer provide the transmission gear, high mechanical efficiency, extended service life, steady performance.

5. Overload protection, variety of limiter and mechanical chain device are reliable and complete, optimal safety device select SAJ30-1.2, which restrict the excessive downward movement of the cage and prevents cage falling accidents.

6. Variable-frequency construction elevator are safe, stead, comfort, start electricity is smaller then the working electricity and efficient.


SC50 Small Building Construction Lifts Single Elevator Cage 500kg Load

SC50 Small Building Construction Lifts Single Elevator Cage 500kg Load
