Powerfoil 24ft High Volume Low Velocity Fan Large HVLS Fan For Agricultural Barns
Powerfoil 24ft High Volume Low Velocity Fan Large HVLS Fan For Agricultural Barns
Powerfoil 24ft High Volume Low Velocity Fan Large HVLS Fan For Agricultural Barns
Powerfoil 24ft High Volume Low Velocity Fan Large HVLS Fan For Agricultural Barns
Powerfoil 24ft High Volume Low Velocity Fan Large HVLS Fan For Agricultural Barns
Powerfoil 24ft High Volume Low Velocity Fan Large HVLS Fan For Agricultural Barns
Powerfoil 24ft High Volume Low Velocity Fan Large HVLS Fan For Agricultural Barns
Powerfoil 24ft High Volume Low Velocity Fan Large HVLS Fan For Agricultural Barns
Specifications
Brand Name :
BIGFANS
Model Number :
SFFCA73
Certification :
CE&ISO
Place of Origin :
Wuhan
Place Of Origin :
Wuhan,China
MOQ :
10 Sets
Price :
Can Be Negotiable
Payment Terms :
T/T,L/C
Supply Ability :
1000 Per Month
Delivery Time :
5-10 Working Days
Packaging Details :
Wooden Box
Motor Type :
PMSM (Permanent Magnet Synchronous Motor)
Type :
Ceiling Fans
Size :
7.3m Diameters
Motor Power :
1.5KW
Control Options :
Remote Control
Noise Level :
40dB
Blade Materia :
Aviation Magnesium-Aluminum Alloy Material
Power Supply :
Single/Three-phase 220V/380V
Usage :
Industrial / Commercial Ventilation
Installation Guide :
Yes (And video guide is available)
Description

Powerfoil 24ft HVLS Industrial Fan Ceiling Mounted Largest HVLS Fan

Product Description:

Engineered for extreme durability, our 24ft Industrial Fan features aerospace-grade aluminum alloy blades and a 3-phase 1.5kw pmsm motor. The corrosion-resistant coating ensures longevity in humid environments, while its aerodynamic design reduces energy consumption by 30%. Ideal for warehouses, workshops, and agricultural barns, this fan supports 5-speed adjustments.

Features:

1. Lower noise level

2. Wider blades

3. IP56-rated against dust, water jets, and other harsh environments

4. Mounts to I-beams, bar joists, solid beams, and purlins

5. Patented airfoil system allows maximum coverage and quiet operation, even at high speeds

Technical Parameters:

DIAMETER
8ft(2.5m)
12ft(3.8m)
16ft(5.0m)
20ft(6.2m)
24ft(7.3m)
MODEL
SFFCA25
SFFCA38
SFFCA50
SFFCA62
SFFCA73
AIR VOLUME
 6500m³/min 8600m³/min
13050m³/min
 14100m³/min 15850m³/min
MAXIMUM SPEED
140RPM
100RPM
70RPM
60RPM
55RPM
WEIGHT
35Kg
51Kg
75Kg
90Kg
127Kg
MOTOR POWER
0.3kw
0.4kw
1.1kw
1.1kw
1.5kw
FULL LOAD CURRENT
1.8AMPS/220V
2.0Amps/380v 2.3Amps/220v
2.4Amps/380v 3.2Amps/220v
3.0Amps/380v 3.5Amps/220v
3.5Amps/380v 5.5Amps/220v

Powerfoil 24ft High Volume Low Velocity Fan Large HVLS Fan For Agricultural Barns

Applications:

Manufacturing Facilities
Warehouses
Distribution Centers
Agriculture & Horticulture
Fitness Centers
Automotive Centers

Powerfoil 24ft High Volume Low Velocity Fan Large HVLS Fan For Agricultural Barns

Support and Services:

The Product Technical Support and Services for the PMSM Series HVLS Industrial Fans include:

- Maintenance recommendations to keep the fan running efficiently and prolong its lifespan.

- Warranty support to address any defects or malfunctions covered under the product warranty.

Powerfoil 24ft High Volume Low Velocity Fan Large HVLS Fan For Agricultural Barns

Packing and Shipping:

Each fan is securely wrapped and placed in a sturdy wooden box with ample cushioning material to prevent any damage during transit, and a set of big fans is composed of a square box and a long box.

Powerfoil 24ft High Volume Low Velocity Fan Large HVLS Fan For Agricultural Barns

FAQ:

Q: Are you factory or trading company?
A: We are factory which established more than 12 years.

Q: How is your motor’s quality compared with others?
A: High efficiency (85%~89%) is our strength.
Low repair rate (less than 0.08%).
All the motors have passed ISO9000, CE.

Q: What is your delivery time?
A: Usually we have stock, delivery time within 7 working days.
If there is customized requirement, time is negotiable.

Q: What other services can you provide?
A: Accepted delivery terms: FOB,CFR,CIF,EXW,DDP,DDU.
Accepted payment type: T/T, L/C;
