EC Fan Coil Unit Motor for Air Conditioner - 1/15HP 300-1150RPM 220-240V 50/60HZ
EC Fan Coil Unit Motor for Air Conditioner - 1/15HP 300-1150RPM 220-240V 50/60HZ
EC Fan Coil Unit Motor for Air Conditioner - 1/15HP 300-1150RPM 220-240V 50/60HZ
EC Fan Coil Unit Motor for Air Conditioner - 1/15HP 300-1150RPM 220-240V 50/60HZ
EC Fan Coil Unit Motor for Air Conditioner - 1/15HP 300-1150RPM 220-240V 50/60HZ
EC Fan Coil Unit Motor for Air Conditioner - 1/15HP 300-1150RPM 220-240V 50/60HZ
EC Fan Coil Unit Motor for Air Conditioner - 1/15HP 300-1150RPM 220-240V 50/60HZ
EC Fan Coil Unit Motor for Air Conditioner - 1/15HP 300-1150RPM 220-240V 50/60HZ
Specifications
Brand Name :
trusTec
Model Number :
TZD-50-10A-UTZ
Certification :
CE
Place of Origin :
Changzhou, China
MOQ :
200 pcs
Price :
Negotiable (FOB/CNF/CIF)
Payment Terms :
T/T, L/C
Supply Ability :
100,000 pcs per month
Delivery Time :
15 days fresh products after order confirmation.
Packaging Details :
Standard carton packing, foam board inside for protection.
Product :
EC Fan coil unit motor
Supply Voltage :
220-240V
Enclosure Type :
TEAO(Totally Enclosed Air Over)
Supply Frequency :
50/60HZ
Thermal Overload :
Equipped With An Automatic Thermal Overload
Current :
0.56A
Phase :
Single Phase
Output Power :
1/15Hp
Mounting :
Bracket
Speed :
300-1150RPM
Bearings :
Ball Bearing
Poles :
10P
Mounting Orientation :
All Angle
Flat Length :
3.15"/80mm
Insulation Class :
Class B
Shaft Length :
11.50"/292mm
Control Mode :
VSP 0-10V
Shaft Diameter :
0.49" / 12mm
Rotation :
CCW(LE)
Lead Length :
62.99"/1600mm
Max. Ambient Temperature :
40℃/104℉
Motor Shell Length :
3.43"/87mm
Description
Send your message to this supplier
Send Now

EC Fan Coil Unit Motor for Air Conditioner - 1/15HP 300-1150RPM 220-240V 50/60HZ

Ask Latest Price
Watch Video
Product Detail
Brand Name :
trusTec
Model Number :
TZD-50-10A-UTZ
Certification :
CE
Place of Origin :
Changzhou, China
MOQ :
200 pcs
Price :
Negotiable (FOB/CNF/CIF)
Contact Supplier
video
EC Fan Coil Unit Motor for Air Conditioner - 1/15HP 300-1150RPM 220-240V 50/60HZ
EC Fan Coil Unit Motor for Air Conditioner - 1/15HP 300-1150RPM 220-240V 50/60HZ
EC Fan Coil Unit Motor for Air Conditioner - 1/15HP 300-1150RPM 220-240V 50/60HZ
EC Fan Coil Unit Motor for Air Conditioner - 1/15HP 300-1150RPM 220-240V 50/60HZ

Changzhou Trustec Company Limited

Verified Supplier
10 Years
jiangsu, changzhou
Since 2011
Business Type :
Manufacturer, Exporter
Main Products :
Commercial Exhaust Fan Motor, Air Conditioner Fan Motor, Synchronous Gear Motor
Total Annual :
5 million-10 million
Employee Number :
50~100
Certification Level :
Verified Supplier
