1000 Liter 1 Layers Water Blowmolding Making Machine BV SGS Certified
1000 Liter 1 Layers Water Blowmolding Making Machine BV SGS Certified
1000 Liter 1 Layers Water Blowmolding Making Machine BV SGS Certified
1000 Liter 1 Layers Water Blowmolding Making Machine BV SGS Certified
1000 Liter 1 Layers Water Blowmolding Making Machine BV SGS Certified
1000 Liter 1 Layers Water Blowmolding Making Machine BV SGS Certified
1000 Liter 1 Layers Water Blowmolding Making Machine BV SGS Certified
1000 Liter 1 Layers Water Blowmolding Making Machine BV SGS Certified
1000 Liter 1 Layers Water Blowmolding Making Machine BV SGS Certified
1000 Liter 1 Layers Water Blowmolding Making Machine BV SGS Certified
1000 Liter 1 Layers Water Blowmolding Making Machine BV SGS Certified
1000 Liter 1 Layers Water Blowmolding Making Machine BV SGS Certified
Specifications
Brand Name :
HUAYU
Model Number :
HYBM-1001
Certification :
CE Certificated,SGS;BV
Place of Origin :
CHINA
MOQ :
1SET
Price :
Negotiate
Payment Terms :
L/C, T/T
Supply Ability :
40SETS PER YEAR
Delivery Time :
4MONTHS
Packaging Details :
EXPORT PACKAGED
Clamping Force :
1800（Kn）
Weight :
39Ton
Warranty :
1 Year
Plastic processed :
HDPE、PE
After-sales service provided :
Engineers service overseas
Color :
Customied
PLC Brand :
Siemens
Description
The 1000L three-layer water bucket blow molding machine is a state-of-the-art piece of equipment designed to meet the high demands of the industry.
This machine features advanced technology and precise engineering, ensuring excellent performance and reliability. It is capable of producing high-quality 1000L three-layer water buckets with consistent dimensions and superior strength.

Condition

new

Video outgoing-inspection
Provided

Machinery Test Report
Provided

Warranty of core components
1 Year

Core Components
PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump

Plastic Processed
HDPE, PE

Place of Origin
Shandong, China

Automation
Automatic

Power (kW)
390

Weight (T)
69

Key Selling Points
High Productivity

Warranty
1 Year

Applicable Industries
Manufacturing Plant, Other

Showroom Location
United States, Brazil, India, Chile

Application
chemical industry package

Brand Name
huayu

Year
2023

Voltage
customized

Dimension(L*W*H)
customized

Hollow part volume
customized

PLC Brand
Siemens

Screw L/D Ratio
30

Screw diameter (mm)
120 mm

No. of Screw Heating Zone
6

Screw Heating Power(kW)
72 kW

Extruder Motor Power(kW)
110 kW

Mold Platen Size(Width)(mm)
1500 mm

Mold Platen Size(Height)(mm)
1600 mm

Air Pressure(MPa)
0.8 MPa

Air Comsumption(m³/min)
1.5 m³/min

Die Head Heating Power(kW)
70 kW

Accumulator Capacity(L)
60 L

After Warranty Service
Life

Blow Moulding Type
Extrusion Blow Moulding

Type
Extrusion Blow Molding Equipment

Marketing Type
Ordinary Product

Product name
Automatic Blowing Molding Machine

Range
IBC tank

CONTROLLER
PLC+Touch Screen

Layer
3 Layers

Parison Control
MOOG 200point

Material
HDPE

1000 Liter 1 Layers Water Blowmolding Making Machine BV SGS Certified1000 Liter 1 Layers Water Blowmolding Making Machine BV SGS Certified1000 Liter 1 Layers Water Blowmolding Making Machine BV SGS Certified
