JMC 5ton Payload Euro 5 Emission Standard Refrigerated Truck with Thermo King Unit
JMC 5ton Payload Euro 5 Emission Standard Refrigerated Truck with Thermo King Unit
JMC 5ton Payload Euro 5 Emission Standard Refrigerated Truck with Thermo King Unit
JMC 5ton Payload Euro 5 Emission Standard Refrigerated Truck with Thermo King Unit
JMC 5ton Payload Euro 5 Emission Standard Refrigerated Truck with Thermo King Unit
JMC 5ton Payload Euro 5 Emission Standard Refrigerated Truck with Thermo King Unit
JMC 5ton Payload Euro 5 Emission Standard Refrigerated Truck with Thermo King Unit
JMC 5ton Payload Euro 5 Emission Standard Refrigerated Truck with Thermo King Unit
JMC 5ton Payload Euro 5 Emission Standard Refrigerated Truck with Thermo King Unit
JMC 5ton Payload Euro 5 Emission Standard Refrigerated Truck with Thermo King Unit
JMC 5ton Payload Euro 5 Emission Standard Refrigerated Truck with Thermo King Unit
JMC 5ton Payload Euro 5 Emission Standard Refrigerated Truck with Thermo King Unit
JMC 5ton Payload Euro 5 Emission Standard Refrigerated Truck with Thermo King Unit
JMC 5ton Payload Euro 5 Emission Standard Refrigerated Truck with Thermo King Unit
Specifications
MOQ :
1
Payload :
5ton
Car Type :
Van
Transport Package :
Nude, Container, RO-RO, Bulk
Price :
15000-35000 per unit
Horsepower :
129HP
Fuel :
Diesel
Specification :
5995x1950x2900mm
Tire :
6.50R16LT
Origin :
Suizhou, China
Applicable Temperature :
-18~0 Degree
Model Number :
CLW
Condition :
New
Material :
Fiberglass
HS Code :
8704223000
Logo :
as Per Customer's Request
Gearbox :
5 Forward & 1 Reverse
Payment Terms :
50% Deposit,Balance should be paid before ship out
Transmission Type :
Manual
Bearing Capacity :
Medium
Production Capacity :
500 Units Per Month
Supply Ability :
10unit per month
Emission Standard :
Euro 5
Certification :
ISO 3C
Trademark :
CLW
Place of Origin :
CHINA
Insulating Layer :
8cm Polyurethane Foam
Brand Name :
CLW
Wheel Base :
3360 mm
Name :
Refrigerated Truck
Description
Cimc Vehicles 5ton 4*2 Chassis Thermo King Unit Refrigerated Truck

Product Description

  • Purpose of the truck : transport frozen fish, meat, fresh vegetables and vaccinum, etc.
  • Main parts of the truck: Refrigerating unit and control system.
  • Features of the truck: International chassis brands and refrigerating unit brands for optional.

Product Specification

General Technical Parameters
Overall Dimension5995 ×1950 ×2900(mm)Gross Vehicle Weight7500(Kg)
Curb Weight2860(Kg)Loading Weight5000(Kg)
Chassis Specification


Chassis parameters

Chassis Brand
CabinSingle, Left Hand Driving, with A/C


Engine

ModelJX493ZLQ6F, 4 Cylinders
Power95KW/129HP
Emission standardEURO V
Displacement2.499L
Fuel typeDiesel
Gearbox5 Forward & 1 Reverse Gear
Front and Rear Axle load2.5T/4.8T
Wheel base3360(mm)
Overhang( Front/Rear)1115/1445(mm)
Angle(Approach/departure)18/15(°)
Brake SystemOil brake
Steering GearPower Assistant
Tire6.50R16LT, 6 Pieces with 1 Spare Tire
Maximum speed95(km/h)
Superstructure


Van

Box size4150 ×2000 ×2100(mm)
MaterialFiberglass
Insulating Layer8cm Polyurethane Foam

BrandTHERMOKING
Truck refrigeration unitModelKV300

Applicable temperature (ºC)-18~0


Remarks

Part Optional: Ventilation slot
Hook
External power supply
Side door
