Specifications
Model Number :
ZHKY2050B
Type :
Load Cell, contactless rotary torque sensor
Place of Origin :
Guangdong, China
Brand Name :
SNC
Use :
Force measurement
Theory :
Convert force into electrical signal
Output :
mV/V, 5-15KHZ/ 4-20 mA/ 0-20mA/ 0-10v/ 0-5v
Description :
ZHKY2050B
Model :
ZHKY2050A
Material :
Aluminum housing, stainless steel shaft
Capacity :
200N.m - 500N.m
Torque accuracy :
0.3%/0.2%/ 0.1%
Output type :
Torque and speed
Power supply :
±15 VDC or 24 VDC
Max rotation speed :
8000 rpm
Speed measurement :
60 or 120 pulses
Packaging Details :
One carton for each dynamic torque sensors, customized requirement acceptable.
Port :
shenzhen
Supply Ability :
100 Piece/Pieces per Month High Accuracy High Speed Shaft Type Torque Speed RPM Sensor 10-1
Price :
$500/pieces 1-4 pieces
Description

ZHKY2050B Rugged in-line rotary sensor torque transducer 200nm 500nm

ZHKY2050B Rugged In-Line Rotary Sensor Torque Transducer Power Supply ±15 VDC or 24 VDC with Aluminum Housing 200nm 500nm

Product Overviews

Model: ZHKY2050A

Item: Noncontact rotary torque sensor

Capacity: 200, 300, 500N.m

Material: Aluminum body, stainless steel shaft

Precision: ±0.3 %F.S, ±0.2 %F.S, ±0.1%

Application: Motor, etc.

Speed measure: YES, max. 8000RPM

If you need higher speed measure MAX.15,000, please refer to ZHKY2051

(Optional accessories available)

Build-in display: Torque speed power display

External Torque speed power display- PY802

English Software

Features:

1, Small size, non-contact rotary torque sensor on the basis of the special technology of strain bridge.

2, Suitable for all kinds of torque measurement occasions requiring small size high speed.

3, Outputs 5~15kHz frequency, or 0-5V, 0-10V, 4~20mA signal, suitable for long distance transmission.

4, Small in size, easy to use and install and strong signal anti-interference ability.

5, It is non-contact, wear-free, suitable for long-term high-speed rotation.

Parameter:

Torque capacity

200, 300, 500N.m

can customize to 1000N.m, 2000N.m or higher.

Speed range

0,100,200-1000,4000,6000,7000, 8000 Varies with Capacity

Excitation voltage:

12-30VDC

15V DC (for frequency signal output),
24V DC (for voltage or current signal output)

Torque signal output

10±5 KHZ (Zero 10kHz) default
4~20mA, 0±5/10VDC, 0-5/10VDC, RS485/RS232

Speed signal output

60 pulse TTL, on-off output

0-5/10VDC, 4-20mA, RS485/ RS232

Accuracy

±0.3% F.S / ±0.2% F.S/±0.1% F.S

Temp Effect on Zero-%RO/

±0.02

Temp Effect on Range-%RO/

±0.02

Working Temperature range:

0 ~ +50℃

Compensated temperature range

0~+60℃

Electrical connection

6-pins, 8 pins

Safety overload:

200 %F.S

Material

Aluminum body, stainless steel shaft

Cable length:

5 m

Cable connection:

Red: Exc+ Black: Exc - Green: Signal + White: Signal-

ZHKY2050B Rugged In-Line Rotary Sensor Torque Transducer Power Supply ±15 VDC or 24 VDC with Aluminum Housing 200nm 500nm

Accessories

ZHKY2050B Rugged In-Line Rotary Sensor Torque Transducer Power Supply ±15 VDC or 24 VDC with Aluminum Housing 200nm 500nm

Product Uses

ZHKY2050B Rugged In-Line Rotary Sensor Torque Transducer Power Supply ±15 VDC or 24 VDC with Aluminum Housing 200nm 500nm

Related Products

ZHKY2050B Rugged In-Line Rotary Sensor Torque Transducer Power Supply ±15 VDC or 24 VDC with Aluminum Housing 200nm 500nm

 ZHKY2050B Rugged In-Line Rotary Sensor Torque Transducer Power Supply ±15 VDC or 24 VDC with Aluminum Housing 200nm 500nm ZHKY2050B Rugged In-Line Rotary Sensor Torque Transducer Power Supply ±15 VDC or 24 VDC with Aluminum Housing 200nm 500nm
ZHKY2050B Rugged In-Line Rotary Sensor Torque Transducer Power Supply ±15 VDC or 24 VDC with Aluminum Housing 200nm 500nm ZHKY2050B Rugged In-Line Rotary Sensor Torque Transducer Power Supply ±15 VDC or 24 VDC with Aluminum Housing 200nm 500nm ZHKY2050B Rugged In-Line Rotary Sensor Torque Transducer Power Supply ±15 VDC or 24 VDC with Aluminum Housing 200nm 500nm
ZHKY2050B Rugged In-Line Rotary Sensor Torque Transducer Power Supply ±15 VDC or 24 VDC with Aluminum Housing 200nm 500nm ZHKY2050B Rugged In-Line Rotary Sensor Torque Transducer Power Supply ±15 VDC or 24 VDC with Aluminum Housing 200nm 500nm ZHKY2050B Rugged In-Line Rotary Sensor Torque Transducer Power Supply ±15 VDC or 24 VDC with Aluminum Housing 200nm 500nm

Company Information

Sensorcon, in accordance with the principle of the introduction of advanced professional ultrasonic gas cleaning, clean Room patches, automatic temperature compensation and detection, high and low temperature testing and thermal experiments, laser welding and printing, CAD design, manufacturing and testing sensor test equipment and production technology ,manufacture all varieties of sensors, high precision, stable performance and also has antiseptic, waterproof, anti-explosion, anti-lightning, etc favored deeply by users.

ZHKY2050B Rugged In-Line Rotary Sensor Torque Transducer Power Supply ±15 VDC or 24 VDC with Aluminum Housing 200nm 500nm

Packaging & Shipping

ZHKY2050B Rugged In-Line Rotary Sensor Torque Transducer Power Supply ±15 VDC or 24 VDC with Aluminum Housing 200nm 500nm

FAQ

1.How to place an order ?
Please provide us more details of what you want, such as: application, measurement range, output, accuracy, thread type, electric connector and other related parameters.

2.Does SNCoffer any discount ?
Yes, if you buy large QTY, please contact us, we will give you a big discount.

3.What terms of payment are available ?
We accept T/T, L/C, Trade assurance, Western Union, Paypal, etc.

4.When will you arrange the production ?
We will arrange the production immediately after receiving your payment.

5.How do you ensure good product quality ?
We have a complete quality control system, all of our products are fully checked by IQC, OQC departments

before shipping to our clients.

6.Do you have warranty ?
Yes, we provide 1 year warranty for most of our products. Some products we offer 15month to 24 months warranty.
