Microwave RTN360 Full-outdoor radio transmission RTN 360
Microwave RTN360 Full-outdoor radio transmission RTN 360
Microwave RTN360 Full-outdoor radio transmission RTN 360
Microwave RTN360 Full-outdoor radio transmission RTN 360
Microwave RTN360 Full-outdoor radio transmission RTN 360
Microwave RTN360 Full-outdoor radio transmission RTN 360
Microwave RTN360 Full-outdoor radio transmission RTN 360
Microwave RTN360 Full-outdoor radio transmission RTN 360
Specifications
Model Number :
RTN 360
Place of Origin :
China
Brand Name :
Huawei
Supply Ability :
200 Piece/Pieces per Week
Price :
Negotiable
Certification :
CE FCC RoHS
MOQ :
Negotiable
Packaging Details :
Export carton package
Delivery Time :
7-15 days
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Model :
RTN 360
Dimensions (H x W x D) :
192.5 mm x 192.5 mm x 70 mm
Weight :
2.5 kg
Antenna :
Built-in panel antenna
Operating frequency band :
59 GHz to 64 GHz
Maximum air capacity :
≥ 600 Mbit/s
Maximum air-interface service throughput :
≥ 1.6 Gbit/s
Maximum switching capacity :
8 Gbit/s
Typical transmission distance :
300 m
RF configuration mode :
1+0 configuration
Description

Microwave RTN360 Full-outdoor radio transmission RTN 360

RTN 360 can work with the small cell site gateway (SCSG) to provide a microwave channel solution for transparent transmission for small cells on the IP RAN.

Item
Specifications
Operating frequency band
59 GHz to 64 GHz
Duplex mode
TDD
Radio working mode (modulation scheme/channel spacing)
Modulation scheme: QPSK, 16QAM, 32QAM
Channel spacing: 200 MHz
AM
Supported
Capacity
Maximum air capacity: ≥ 600 Mbit/s
Maximum air-interface service throughput: ≥ 1.6 Gbit/s
Maximum switching capacity: 8 Gbit/s
Typical transmission distance
300 m
Service port
Two GE electrical service ports
Two GE electrical service ports
1+0 configuration
Service type
Native Ethernet services: E-Line service and E-LAN service
PW-carried Ethernet services: E-Line service, E-Aggr service, and E-LAN (VPLS) service (VPLS standing for virtual private LAN service)
QoS/HQoS
Supported
MPLS Tunnel
Supported
PWE3
Supported
Clock feature
Clock sources: microwave link clocks and synchronous Ethernet clocks
IEEE 1588v2 time synchronization
ITU-T G.8275.1 time synchronization
Power supply mode
Power over Ethernet, supplied by the AC power injector (PI), DC power injector (PI), and RTN 900 IDUs.
Dimensions (H x W x D)
192.5 mm x 192.5 mm x 70 mm
Weight
2.5 kg
Antenna
Built-in panel antenna

our business scope include Router/Switch/BRAS, GPON/EPON/FTTX, Optical TRANSMISSION(SDH/DWDM/PTN/Microwave), DSLAM/PSTN/MSAG/MSAN, Firewall/Security Gateway, Power Energy/UPS/indoor Outdoor Cabinet, Video Conference, WLAN etc., We also supply used and refurbished wireless and core network, including Huawei/Ericsson/ NSN/Alcatel/ZTE, GSM/UMTS/LTE, BBU, RRU, BTS.
