Cast Iron High Security Dryer Cylinder for Papermaking with Ra 0.1-0.4 Roughness and 500-1200m/min Speed
Cast Iron High Security Dryer Cylinder for Papermaking with Ra 0.1-0.4 Roughness and 500-1200m/min Speed
Cast Iron High Security Dryer Cylinder for Papermaking with Ra 0.1-0.4 Roughness and 500-1200m/min Speed
Cast Iron High Security Dryer Cylinder for Papermaking with Ra 0.1-0.4 Roughness and 500-1200m/min Speed
Cast Iron High Security Dryer Cylinder for Papermaking with Ra 0.1-0.4 Roughness and 500-1200m/min Speed
Cast Iron High Security Dryer Cylinder for Papermaking with Ra 0.1-0.4 Roughness and 500-1200m/min Speed
Specifications
Brand Name :
HUATAO
Model Number :
DRYER CYLINDER
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1
Price :
2000USD/pc-5000USD/pc
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
100 PCS/Year
Delivery Time :
5-8 Weeks
Packaging Details :
Wooden Box
Product Name :
Cast Iron High Security Dryer Cylinder For Papermaking Dryer Section
Key Words :
Dryer, Dryer Cylinder, Drum Cylinder
Roughness :
Ra 0.1-0.4
Working Speed m/min :
500-1200m/min
Material :
Cast Iron, Steel
Hardness :
HB190-280
HS Code :
84399900
Max Steam Pressure :
1 Mpa
Description
Cast Iron High Security Dryer Cylinder For Papermaking Dryer Section
Product Description

The Cast Iron High Security Dryer Cylinder is an essential component in papermaking machinery, designed to continuously dry formed paper blanks after pulp processing. Multiple drying cylinders are arranged crosswise within papermaking machines to ensure efficient drying.

Dryer Cylinder Production

Papermaking drying cylinders are drum-type pressure vessels with rotatable shafts at both ends. Steam enters through the hollow shaft at one end for drying, while condensed water is discharged through the opposite shaft. These cylinders are cast from high-quality iron with polished outer surfaces, utilizing graphite flakes in the cast iron to prevent paper sticking during the drying process.

Dryer Cylinder Main Technical Data
Diameter Material Design Pressure (MPa) Hardness (HB) Face Length (mm) Working Speed (m/min) Roughness (Ra)
Φ1500 HT250-HT350 0.3-1.1 190-240 1450-10000 500-1200 0.1-0.4
Φ1800 HT250-HT350 0.3-1.1 190-240 1450-10000 500-1200 0.1-0.4
Φ2000 HT250-HT350 0.3-1.1 190-240 1450-8000 500-1200 0.1-0.4
Φ2500 HT250-HT350 0.3-1.1 220-260 1450-8000 500-1200 0.1-0.4
Φ3000 HT350 0.3-1.1 230-260 1450-8000 500-1200 0.1-0.4
Φ3660 HT350 0.3-1.1 230-260 1450-8000 500-1500 0.1-0.4
Φ3800 HT350 0.3-1.1 230-260 1450-8000 500-1500 0.1-0.4
Cast Iron High Security Dryer Cylinder for Papermaking with Ra 0.1-0.4 Roughness and 500-1200m/min Speed
About Huatao Group

Founded in 2008, Huatao Group is a leading supplier of industrial rollers with over 15 years of experience serving the paper, corrugated board, rubber, plastic, and nonwoven fabric industries.

Our Product Range
  • Paper Industry: Forming rollers, vacuum couch rollers, dryer cylinders, calender rollers, and more
  • Plastic & Rubber: Chill rollers, MDO rollers, corona treatment rollers, carbon fiber rollers
  • Nonwoven Fabric: Cylinder rollers, doffer rollers, embossing rollers, cooling rollers

With a commitment to innovation and quality, Huatao Group exports to over 96 countries worldwide. We understand unique customer requirements and match them with the most suitable manufacturing solutions, ensuring reliable products and continuous service.
