Tiny Straightness Runout Induction Heating Roller For Thermal Print And Carbon Fiber Hot Press
Tiny Straightness Runout Induction Heating Roller For Thermal Print And Carbon Fiber Hot Press
Tiny Straightness Runout Induction Heating Roller For Thermal Print And Carbon Fiber Hot Press
Tiny Straightness Runout Induction Heating Roller For Thermal Print And Carbon Fiber Hot Press
Specifications
Packaging Details :
Wooden Box
Processing Accuracy :
Roller surface temperature difference ≦±1℃
Brand Name :
HUATAO
Price :
2000USD/pc-5000USD/pc
Place of Origin :
CHINA
Delivery Time :
5-8 weeks
Material :
high-quality 45# steel, alloy steel, and high-quality steel
Certification :
ISO
Key Words :
Electromagnetic Induction Heating Roller, heating roller
Surface Treatment :
Hard chromium plating, Teflok, spray ceramic or tungsten carbide
Payment Terms :
L/C,T/T,Western Union
Model Number :
ELECTROMAGNETIC INDUCTION HEATING ROLLER
MOQ :
1
Product Name :
Tiny Straightness Runout Induction Heating Roller For Thermal Print And Carbon Fiber Hot Press
Straightness Runout :
≤0.01mm
Supply Ability :
100 PCS/Year
Description
Tiny Straightness Runout Induction Heating Roller For Thermal Print And Carbon Fiber Hot Press
Product Features
Uniform Heat Distribution: Innovative electromagnetic induction structure delivers consistent surface heat with temperature deviation below ±1℃, matching low medium and high temperature diverse production conditions.
Accurate Temperature Regulation: High-precision sensing modules stabilize working temperature at ±0.1℃, matched with ceramic insulation and water-cooled winding to realize long-term steady operation under 600℃ extreme working condition.
Operational Safety: Original electromagnetic direct heating cuts hidden troubles like cylinder swell, medium leakage and burst failure generated from traditional thermal oil heating configuration.
Eco Friendly Performance: Abandon heat conduction oil and circulating steam entirely, thoroughly avoid liquid spillage, industrial waste and harmful exhaust discharge during equipment running.
Outstanding Energy Saving: Cut comprehensive power consumption by 50~70% versus conventional heating rollers, meanwhile the overall heating response speed is doubled effectively.
Technical Specifications
Material High-quality 45# steel, alloy steel
Roller Surface Temperature Difference ≦±1℃
Heating Method Electromagnetic induction heating
Surface Treatment Hard chromium plating, Teflok, spray ceramic or tungsten carbide
Processing Accuracy ≤0.005mm
Straightness Runout ≤0.01mm
Tiny Straightness Runout Induction Heating Roller For Thermal Print And Carbon Fiber Hot Press
Application Fields
Printing, packaging, textiles, non-woven fabrics, thermal transfer printing, laser anti-counterfeiting, electronics, specialty paper, paper drying, pre-coated film lamination, laminated iron/aluminum production, optical films, stretch films, PTFE films, solar panel lamination, lithium battery components, PTFE coated filters, copper clad laminates, polyimide synthesis, chemical fibers, carbon fibers, sheet calendering, rubber/plastic/metal plate processing, high-temperature material composites.
About Huatao Group
Located in Shijiazhuang, Hebei, China, we specialize in manufacturing rollers for BOPET, BOPP, CPP lines, slitters, metalizers, and laminating machines. We welcome partnerships to create a prosperous future.
