Multi Bag Filter Used in Industrial Water Industry
Multi Bag Filter Used in Industrial Water Industry
Multi Bag Filter Used in Industrial Water Industry
Multi Bag Filter Used in Industrial Water Industry
Specifications
Brand Name :
HUATAO
Model Number :
HT-068
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1 Set
Price :
By negotiation
Payment Terms :
T/T,L/C,Western Union,MoneyGram
Supply Ability :
100 Set/month
Delivery Time :
15-25days
Packaging Details :
standard export wooden box
Goods :
Multi Bag Filter Used in Industrial Water Industry
Flow Rate :
1-45M3 /H
Filter Housing :
SS316L Or SS304
Bag Material :
PTFE or Other
Filtration Precision :
0.5-3000um
Warranty Period :
1 Year
Surface Treatment: :
Mirror Polish or sandblasting
Description
Multi Bag Filter Used in Industrial Water Industry
Introduction For Multi Bag Filter Used in Industrial Water Industry
Liquid gets into the filter bag from side or bottom feed holes. It is pushed by flowing power and steady pressure to make the bag open fully. The liquid spreads evenly across the whole inner side of the bag. All dirt stays inside the bag, and clean filtered liquid flows into transport tubes.
Working Principle For Multi Bag Filter Used in Industrial Water Industry

The liquid enters from the side or lower inlet of the filter bag.The filter bag is expanded due to the impact of the liquid and the uniform pressure surface.The liquid material is evenly distributed on the inner surface of the whole Filter bag.The filtered liquid passing through the filter bag and flow into the pipeline.The particle impurities are intercepted in the filter bag.

Multi Bag Filter Used in Industrial Water Industry

Technical Parameters For Multi Bag Filter Used in Industrial Water Industry
Filter Model Filter Inner Dia. Filter Height Thickness Filter Area
HT-D2 350mm 1000mm 4mm 0.5
HT-D3 450mm 1000mm 6mm 0.7
HT-D4 550mm 1000mm 6mm 1.0
HT-D5 650mm 1000mm 6mm 1.6
HT-D12 1000mm 1000mm 6mm 3
HT-D24 1200mm 1200mm 6mm 6

Feature For Multi Bag Filter Used in Industrial Water Industry

1.Operating temperature <200°C (depending on seal material);

2.Precision-manufactured from high-quality,pure SS304/316L stainless steel;

3.Quick-opening lid design reduces labor costs;

4.Optimized support basket openings increase flow rate and filter bag life;

5.High-quality butt-weld connections provide strength and corrosion resistance;

6.Oval bottom provides a perfect fit for the filter bag;

7.Multiple models with different filter areas are available to meet various flow requirements;

8.Matte sandblasted exterior surface for an elegant and easy-to-clean look;

9.Mirror-polished interior surface meets sanitary requirements;

10.O-type elastomeric seal seals the housing for easy tightening and durability;

11.High-precision filtration,suitable for all fine particles and suspended solids,with a filtration range of 0.5 to 200 microns.

Application For Multi Bag Filter Used in Industrial Water Industry
Bag filter is mainly used to filter impurities in water,beverages and chemical Liquids.
