Kraft Paper Making Paper Machine Fabric Single Layer 4 Shed Weaving Type
Kraft Paper Making Paper Machine Fabric Single Layer 4 Shed Weaving Type
Kraft Paper Making Paper Machine Fabric Single Layer 4 Shed Weaving Type
Kraft Paper Making Paper Machine Fabric Single Layer 4 Shed Weaving Type
Kraft Paper Making Paper Machine Fabric Single Layer 4 Shed Weaving Type
Kraft Paper Making Paper Machine Fabric Single Layer 4 Shed Weaving Type
Specifications
Brand Name :
HUATAO
Model Number :
Double Layer Forming Fabric of paper machine clothing
Place of Origin :
China
MOQ :
10 square meter
Price :
Price accept negotiation
Payment Terms :
L/C,T/T,Western Union,MoneyGram
Supply Ability :
1200 suqare meter per week
Delivery Time :
3-4 weeks
Packaging Details :
pp bags/wooden box
usage :
kraft paper forminig wire
material :
polyester
packaging :
standard export package
Description
Kraft Paper Making Paper Machine Fabric Single Layer 4 Shed Weaving Type
Product Specifications
Attribute Value
Usage Kraft paper forming wire
Material Polyester
Technical Specifications
FABRIC CODE Warp Density Weft Density Warp Diameter Weft Diameter Air Permeability FSI DI
40203 40 29 0.15 0.2 285 135 14.1
25284 28 23 0.22 0.28/0.28 400 77 11.4
25305 28 22 0.22 0.3/0.3 505 70 11.3
22408-1 28 17 0.22 0.4/0.4 505 70 8.7
22408-2 28 17 0.22 0.4/0.4 560 69 9.1
Product Description

Polyester Forming Fabric is categorized by weaving type into 4-shed, 5-shed, 8-shed, 16-shed, and 24-shed variations. It is also classified by structure as single layer, double layer, two-and-a-half layer, and three-layer fabric.

The 4-shed and 5-shed series single layer polyester forming mesh fabric is the standard type for paper making, ideal for producing cultural paper (single glue, double glue, color glue), printing paper, glazed paper, packing paper, and common newsprint. Designed for standard fourdrinier paper machines.

8-shed single layer polyester forming mesh fabric is optimized for high-volume packing paper production including kraft paper, cardboard, and corrugated paper, while also suitable for common printing paper. Compatible with standard fourdrinier paper machines.

16-shed double and a half layer polyester forming mesh fabric excels in producing quality printing paper such as offset printing paper, copperplate paper, newsprint, and paper series (wrap paper and filter tips paper). Also effective for tissue paper and various board paper applications. Recommended for medium to high-speed paper making machines.

Multi-shed three-layer polyester forming mesh fabric is engineered for premium printing paper, tissue paper, and paper production. Designed for high-speed paper making machines.

Key Features
  • Extended service life with excellent wear resistance and minimal net loss
  • High fatigue resistance with resistance to acids and weak alkalis
  • Minimal mesh marks for superior forming quality
  • Lightweight design for easy transportation and installation
Kraft Paper Making Paper Machine Fabric Single Layer 4 Shed Weaving Type Kraft Paper Making Paper Machine Fabric Single Layer 4 Shed Weaving Type
