Fine Modular Polyurethane Vibrating Screen Mesh 610x610mm with High Screening Efficiency
Fine Modular Polyurethane Vibrating Screen Mesh 610x610mm with High Screening Efficiency
Fine Modular Polyurethane Vibrating Screen Mesh 610x610mm with High Screening Efficiency
Fine Modular Polyurethane Vibrating Screen Mesh 610x610mm with High Screening Efficiency
Fine Modular Polyurethane Vibrating Screen Mesh 610x610mm with High Screening Efficiency
Fine Modular Polyurethane Vibrating Screen Mesh 610x610mm with High Screening Efficiency
Fine Modular Polyurethane Vibrating Screen Mesh 610x610mm with High Screening Efficiency
Fine Modular Polyurethane Vibrating Screen Mesh 610x610mm with High Screening Efficiency
Specifications
Brand Name :
HUATAO
Model Number :
HT-013
Place of Origin :
China
MOQ :
10 pieces
Price :
USD 35-45 per piece
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
10000 pieces per month
Delivery Time :
7 - 10 working days
Packaging Details :
air bubble film + wooden box
Material :
Polyurethane
Description
Fine Modular Polyurethane 610x610mm Vibrating Screen Mesh
High Wear Resistant Fine Modular Polyurethane Vibrating Screen Mesh
Product Overview

Polyurethane PU screen mesh is fabricated from advanced polyurethane materials with embedded metal framework structure, combining all the characteristics of rubber sieve while offering superior wear resistance, higher screening accuracy, and better tear resistance.

Available Sizes & Specifications
0.054mm 0.063mm 0.068mm
0.074mm 0.10mm 0.12mm
0.15mm 0.18mm 0.20mm
0.22mm 0.25mm 0.30mm
0.35mm 0.43mm 0.50mm
0.70mm ≥1.00mm

Common Panel Sizes: 305×305mm, 300×300mm, 305×610mm
Custom Sizes: Available upon request
Slit Dimensions: Length 4-16mm, Width 0.1-2.5mm
Structural Styles: Setting type, bolt link, press bar coupling, screen hook coupling

Fine Modular Polyurethane Vibrating Screen Mesh 610x610mm with High Screening Efficiency Fine Modular Polyurethane Vibrating Screen Mesh 610x610mm with High Screening Efficiency
Key Features & Benefits
  • High Screening Efficiency: 2-5 times more efficient than ordinary screens
  • Large Bearing Capacity: 2.5 times greater than rubber sieves
  • Long Service Life: 6 months to over 1 year of continuous operation
  • Excellent Abrasion & Corrosion Resistance: Suitable for water or oil media conditions
  • Low Maintenance: Non-clogging holes and self-cleaning design
  • Reduced Noise: Superior vibration-absorbing performance
  • Optimized Screen Hole Design: Prevents particle blockage
  • Wide Application Range: Mining, metallurgy, coal, coking, chemical and other industries
  • Excellent Wet Performance: Effective operation in water-based conditions
Applications

Our polyurethane screens and sieve plates are widely used in metallurgy, mining, coal screening, building materials, water conservancy, construction industry, steel plate punching mesh, wire mesh, and stainless steel plate products. They offer advantages including light weight, high efficiency, non-clogging operation, anti-friction properties, impact resistance, tear resistance, long service life (2-3 times longer than stainless steel plates), low noise, and easy installation.

Fine Modular Polyurethane Vibrating Screen Mesh 610x610mm with High Screening Efficiency
