Specifications
Place of Origin :
Beijing
Brand Name :
HUATEC
Certification :
ISO, CE, GOST
Model Number :
HFD
MOQ :
1pcs
Packaging Details :
Standard export package
Delivery Time :
1-4days
Payment Terms :
T/T, Paypal, Western Union
Supply Ability :
500pcs per month
Material :
Zinc alloy
Angle :
0-90degres
Connector :
Lemo 00 Lemo 01 BNC Microdot
Frequency :
0.5Mhz-10MHz
Description

Straight / Angle Beam Probe UT probe UT transducer Ultrasonic Transducer Probe

We offer all kinds of ultrasonic transducer as customer request with different element and composite material.

Ultrasonic Transducer
Probe type
Designation
Angle
Transducer element size [mm]
Frequency [MHz]
Straight / Angle Beam Probe UT probe UT transducer Ultrasonic Transducer Probe
angle probe
HFD 9x8-2M-35
35°
8x9
2 MHz
HFD 9x8-2M-45
45°
8x9
2 MHz
HFD 9x8-2M-60
60°
8x9
2 MHz
HFD 9x8-2M-70
70°
8x9
2 MHz
HFD 9x8-2M-80
80°
8x9
2 MHz
HFD 9x8-4M-35
35°
8x9
4 MHz
HFD 9x8-4M-45
45°
8x9
4 MHz
HFD 9x8-4M-60
60°
8x9
4 MHz
HFD 9x8-4M-70
70°
8x9
4 MHz
HFD 9x8-4M-80
80°
8x9
4 MHz















angle probe
HFD 22x20-2M-35
35°
20x22
2 MHz
HFD 22x20-2M-45
45°
20x22
2 MHz
HFD 22x20-2M-60
60°
20x22
2 MHz
HFD 22x20-2M-70
70°
20x22
2 MHz
HFD 22x20-2M-80
80°
20x22
2 MHz
HFD 22x20-4M-35
35°
20x22
4 MHz
HFD 22x20-4M-45
45°
20x22
4 MHz
HFD 22x20-4M-60
60°
20x22
4 MHz
HFD 22x20-4M-70
70°
20x22
4 MHz
HFD 22x20-4M-80
80°
20x22
4 MHz
Probe type
Designation
Transducer element* diameter[mm]
Frequency[MHz]
Standard straight probe

Straight / Angle Beam Probe UT probe UT transducer Ultrasonic Transducer Probe
HFD 10-2M
Ø 10
2 MHz
HFD 10-4M
Ø 10
4 MHz
HFD 10-6M
Ø 10
6 MHz
HFD 20-2M
Ø 20
2 MHz
HFD 20-4M
Ø 20
4 MHz
HFD 20-6M
Ø 20
6 MHz
Probe type
Designation
Transducer element* diameter[mm]
Frequency[MHz]
Dual straight probe
Straight / Angle Beam Probe UT probe UT transducer Ultrasonic Transducer Probe
PQ 2/10-2M
Ø 10
2 MHz
PQ 2/10-4M
Ø 10
4 MHz
PQ 2/10-6M
Ø 10
6 MHz
PQ 2/20-2M
Ø 20
2 MHz
PQ 2/20-4M
Ø 20
4 MHz
PQ 2/20-6M
Ø 20
6 MHz
Probe type
Designation
Angle
Transducer element* diameter[mm]
Frequency[MHz]
Straight / Angle Beam Probe UT probe UT transducer Ultrasonic Transducer Probe

Dual angle probe
HFD 13x8-2M-60
60°
8x13
2 MHz
HFD 13x8-2M-70
70°
8x13
2 MHz
HFD 20x10-2M-60
60°
10x20
2 MHz
HFD 20x10-2M-70
70°
10x20
2 MHz
HFD 13x8-5M-60
60°
8x13
5 MHz
HFD 13x8-5M-70
70°
8x13
5 MHz

Note:

1.Other special probes are available such as Angle beam probe with pour water, probe for variable angle, probe for locomotive piston, beam TR probe with pour water, probe for railcar axle, probe for demarcate echo, cleanout machine tansducer etc.

2.We offer all kinds of probe with customer request.


Testing Curve Report for a Transducers (optional by order)


Straight / Angle Beam Probe UT probe UT transducer Ultrasonic Transducer Probe

Longitudinal Wave Probes (Straight Probe)

Straight / Angle Beam Probe UT probe UT transducer Ultrasonic Transducer Probe

Transverse Wave Angle Beam Probes

Straight / Angle Beam Probe UT probe UT transducer Ultrasonic Transducer Probe

Longitudinal Wave and Dual Crystal Angle Beam Probe

*Please indicate the frequency and Focus range together with probe code in your order list.

*For example: HFD 8×13-2 2.5M10 means Element size: 8 × 13, Frequency: 2.5MHz, Focus: 10mm

Dual Crystal Straight Probe

*Please indicate the frequency and Focus range together with probe code in your order list.

*For example: HFD2/12-2.5M10 means Element size: Ø12 Frequency: 2.5MHz Focus: 10mm

Short Approach Probe and Special Probe with Protective Membrane

*Please indicate the frequency and Focus range together with probe code in your order list.

*For example: HFD7/9 5MHz F10 means Element size: 7×9 Frequency: 5MHz Focus: 10mm
