88 kw YUNNEI Engine HQ-YL8000 8 Ton Vibratory Road Roller for Asphalt Construction
88 kw YUNNEI Engine HQ-YL8000 8 Ton Vibratory Road Roller for Asphalt Construction
Specifications
Applicable Industries :
Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising C
Showroom Location :
Canada, Russia, UAE, Tajikistan
Condition :
New
Type :
Vibratory Roller
Travel Speed :
2-12km/h
Grade Ability :
30%
Place of Origin :
Shandong, China
Brand Name :
HUAQI
Power :
110 kw, 92 KW, 88kw
Dimension(L*W*H) :
4550*2090*2750mm
Weight :
8000kg
Warranty :
1 Year
Hydraulic Pump Brand :
Huade
Hydraulic Valve Brand :
HYDAC
Engine Brand :
YUNNEI
UNIQUE SELLING POINT :
EPA Engine
Drum diameter :
1200mm
Drum :
Single Drum Roller
Exciting Force :
120KN
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Marketing Type :
Ordinary Product
Warranty of core components :
1 Year
Core Components :
Motor, Pump, Engine
Product Name :
Single Steel Wheel Paver Roller
Name :
8t road roller
Engine Power :
88 kw
Vibration Frequency :
75hz
Keywords :
Wheel Roller
Vibration Type :
Hydraulic vibration
Nominal Amplitude :
0.5mm
Starting Method :
Electric Start
Steel Wheel Width :
1850 mm
Key words :
Hydraulic Vibratory Road Roller
Packaging Details :
* Wooden box with Standard Export Packing
* Film plastic and wooden crate with manufacturer logo outsides.
* All of the productions are inspected carefully by QC before delivery.
Port :
Qingdao,Shanghai,Guangzhou
Supply Ability :
1000 Set/Sets per Month road roller
Price :
$8,500.00/sets 1-9 sets
MOQ :
1 unit
Description
88 kw YUNNEI Engine HQ-YL8000 8 Ton Vibratory Road Roller for Asphalt Construction
Asphalt Road Roller Compactor Machine 8.0 Ton Roller Brand New Vibratory Road Roller
The Single Steel Wheel Paver Roller is a sturdy and high-performing compaction machine designed for a wide range of road construction and compaction tasks. It is available with either a reliable Changchai or Changfa 390 engine, providing an impressive power output of 88kw, ensuring exceptional performance and efficiency. Operating at speeds ranging from 2 to 12 km/h, the offers versatility and excellent maneuverability on various terrains. With an outstanding climbing ability of 30%, it can handle steep inclines and challenging working environments with ease. The paver roller is equipped with a nominal amplitude of 0.7 mm and operates at a vibration frequency of 75 Hz, delivering effective and consistent compaction results. The powerful excitation force of 120 KN ensures optimal compaction efficiency, achieving superior density for different construction materials.
Discounted
88 kw YUNNEI Engine HQ-YL8000 8 Ton Vibratory Road Roller for Asphalt Construction
Product Description
88 kw YUNNEI Engine HQ-YL8000 8 Ton Vibratory Road Roller for Asphalt Construction
88 kw YUNNEI Engine HQ-YL8000 8 Ton Vibratory Road Roller for Asphalt Construction
88 kw YUNNEI Engine HQ-YL8000 8 Ton Vibratory Road Roller for Asphalt Construction
88 kw YUNNEI Engine HQ-YL8000 8 Ton Vibratory Road Roller for Asphalt Construction
88 kw YUNNEI Engine HQ-YL8000 8 Ton Vibratory Road Roller for Asphalt Construction
88 kw YUNNEI Engine HQ-YL8000 8 Ton Vibratory Road Roller for Asphalt Construction
Specification
Parameter
Value
Parameter
Value
Name
HQ-YL8000 Single Steel Wheel Paver Roller
Engine Brand
Yunnei
Travel Speed
2-12 km/h (Forward/Reverse)
Engine Model
4102
Climbing Ability
30%
Engine Power
88 kw
Nominal Amplitude
0.6 mm
Vibration Frequency
75 Hz
Excitation Force
120 KN
Static Linear Load
90 N/cm
Vibration Mode
Hydraulic Vibration
Fuel Consumption Rate
≤ 310 g/kWh
Starting Method
Electric Start
Steel Wheel Width
1850mm
Operating Weight
8000 kg
Steel Wheel Diameter
1200 mm
Fuel Tank Capacity
85 L
Exterior Dimensions
4550*2090*2750mm
88 kw YUNNEI Engine HQ-YL8000 8 Ton Vibratory Road Roller for Asphalt Construction
Company Profile
88 kw YUNNEI Engine HQ-YL8000 8 Ton Vibratory Road Roller for Asphalt Construction
88 kw YUNNEI Engine HQ-YL8000 8 Ton Vibratory Road Roller for Asphalt Construction
Product packaging
88 kw YUNNEI Engine HQ-YL8000 8 Ton Vibratory Road Roller for Asphalt Construction
88 kw YUNNEI Engine HQ-YL8000 8 Ton Vibratory Road Roller for Asphalt Construction
Certifications
88 kw YUNNEI Engine HQ-YL8000 8 Ton Vibratory Road Roller for Asphalt Construction
FAQ
1.Q:Can the factory support mass production? Can i purchase a customized sample first? A:Dear friends, our company can support mass production. It can mass produce 200+Road roller in one month, can support customization, can customize colors and logos, etc. 2.Q:Can it be transported to my door? I want to get my favorite mini excavator soon? A:Of course, my friend, but if your family is located very close to the port, we suggest that you can go directly to the port to transport your goods, so you can save a lot of money! If the distance is long, you can find an inland transportation company by yourself, and we can communicate with him; we can also find an agency for you, but the toll will be very high (not recommended)during transportation, we will not charge any intermediate fees and additional service fees other than freight. We just want you to get your favorite Road roller earlier. 3.Q:How can i guarantee after-sales after i buy it? A:Dear friends, our machine has a one-year/1000h work warranty period. During this time, if there is any problem
