Advantages of short-stroke back loading structure
1.The extrusion stroke of the short-stroke extruder is shorter than that of a conventional extruder, reducing the frame opening and increasing the rigidity of the stress frame by 30% compared to traditional extruders.
2.The main side cylinder volume is reduced, which decreases the usage of hydraulic oil, thereby improving speed control accuracy and pressure control accuracy. This shortens the time needed for pressure increase and release, reduces energy consumption, and minimizes the impact of oil during pressure relief.
3.The gasket circulation system is eliminated, which reduces reactive operation time and lowers the power consumption of the production line. Non-extrusion time is reduced by 15%.
4.A translation manipulator driven by a servo motor is used, further reducing non-extrusion time by 15%.
Application Field
Construction Industry
Industrial Trade
New Energy Industry
Photovoltaic Industry
Our hydraulic aluminum extrusion machine is versatile and applicable across all these industries. Aluminum profiles produced by our machine have a wide range of uses, including:
Roofs, Walls, Doors, and Windows: Durable and lightweight, making them ideal for various structural and decorative purposes.
Frames and Reticulated Shell Structures: Providing strong, stable support for complex architectural designs.
Grid Structures and Glass Curtain Wall Support Systems: Ensuring robust and aesthetically pleasing facades.
Awnings and Pedestrian Bridges: Offering protection and functionality in outdoor spaces.
Interior and Exterior Decorative Panels, Partitions, Ceilings, and Suspended Ceilings: Enhancing the aesthetic and functional qualities of buildings.
Railings and Handrails: Combining safety with modern design.
Store Containers and Construction Formwork: Widely used for their strength, versatility, and ease of assembly.
These applications demonstrate the effectiveness and reliability of our aluminum extrusion machine in both industrial and civil building projects.
Technical Characteristics and Specification
1. The key components of the hydraulic aluminum extrusion machine—such as the container, extrusion pad, shear blade, and ingot feeder—feature mature designs and exhibit a low failure rate.
2. The equipment experiences minimal impact and vibration, reducing the likelihood of oil leakage.
3. The machine boasts quick responsiveness and high efficiency, resulting in reduced non-extrusion time.
4. It offers high precision with the ability to control extrusion speed accurately to within ±0.1mm.
5. The machine is highly automated and supports intelligent production, lowering the requirements for operator skill and maintenance efforts.
Shipment Pictures
Workshop show
FAQ
Q1: How is the quality of Huanan Brand machine and the service life?
Huanan Brand is one of the best equipment for extrusion manufacturers in China. According to the feedback of old customers, under normal circumstances, the life of the machine can reach 15 years or more. Many well-know aluminum manufacturers are also our cooperative customers.
Q2: How to choose the right type machine ?
Please tell to us what kind of products you make ?Provide the profile sectional drawing dimensions ,we will according your size to calculate the suitable machine size.
Q3. Will Huanan provide installation service?
When the aluminum extrusion machine arrives at the customer's factory and meets the installation conditions, we will send technicians to the site to install it and train customer employees on how to use the equipment correctly.
Q4:What is the delivery time of Huanan Machines?
For ordinary small-sized machine such as 600-1000MT, 30 days; middle-sized machine such as1250-1800MT, 45-60 days, for big-sized machine such as 2000-3000MT, 180 days.More than 3000MT, half year to one year delivery date. We could also design and make the whole production line for our customer, around 3-10 months.
Q5: What services Huanan can do for you :
Huanan provides comprehensive one-stop services, encompassing pre-sales, in-sales, and after-sales support. Our offerings include:
Technical Consultation and Support: Expert advice and assistance throughout the project.
Customized Production Proposals: Tailored solutions based on customer requirements.
End-to-End Services: Covering design, manufacturing, inspection, uploading, shipping, and provision of all original documents.
Lifetime Support: Including installation, technology training, and ongoing maintenance.
