Specifications
Brand Name :
HG CRANE
Model Number :
U
Place of Origin :
Henan China
MOQ :
1
Price :
USD5000
Payment Terms :
T/T
Delivery Time :
30 work days
Color :
Red / Customizable
Material :
Steel
Capacity :
20CBM
Drive Type :
Four-rope Mechanical Drive
Max Opening :
About 5000mm
Suitable Crane :
25-32 Ton Double-drum Crane
Description

In all types of cranes, equipped with two set of motor reel (i.e. electric hoist), each reel is provided with two wire rope where in the two into a group were rooted in the grab balance rack ends support, another group of wire rope through the upper
beam and the lower cross beam of the pulley pulley, pulley set up consisting of, close combat unit effect of.


At the beginning of the operation, to support the rope grab lifting in the proper position, and then down to open and close the rope, then on the lower beam deadweight force fighting department following beam shaft as the center will open when the bucket of bucket, a touch block to two ear plates collide, namely the bucket open to a maximum. Bucket opening. upper crossbeam and a lower cross beam pulley pulley center distance is increased, then the support wire rope fall, will open the grab, fall in to grab the loose deposit above, and then close around the opening and closing of steel wire rope, the pulley and the lower cross beam on the central distance of the pulley is restored to its original position, so that finished capture material process.In the closed and fights the Ministry had been filled with material, finally enhance the open-close rope, the grab is also liftedby crane, moved to the unloading area,opening bucket unloading place capture material.


With a 20 cubic meter large capacity design, this grab bucket features a high-strength structure, excellent wear resistance and reliable mechanical operation. It requires no hydraulic power, resulting in low maintenance costs and high working efficiency, making it an ideal choice for bulk cargo handling operations.
High Performance 20CBM Four Rope Grab Bucket for Warehouse Material Handling
Models Volume (m³) Duty Type Material Specific Gravity (t/m³) Grabbing Capacity (t) Pulley Multiplier Number of Opening/Closing Ropes Number of Supporting Ropes Steel Wire Rope Diameter (mm) Pulley Diameter (mm) Opening/Closing Time (s) Grab Dead Weight (t) Rated Crane Capacity (t) Total Grab Height (mm) Bucket Length × Width × Height (mm) Maximum Opening Size (mm)
U1 1 Heavy Duty >1.8~1.9 1.8~1.9 5 2 2 Φ14 Φ350 14 2.065 5T 2635 1850×1150×673 2544
U2 1.5 Medium Duty >1~1.8 1.5~2.1 5 2 2 Φ14 Φ350 12.5 2.235 5T 2765 2150×1250×745 2700
U3 2.5 Light Duty >0.5~1 1.25~2.5 3 2 2 Φ14 Φ350 8 2.285 5T 2985 2350×1500×927 3200
U27 2 Medium Duty >1~1.2 2~2.4 5 2 2 Φ16 Φ400 12 2.5 5T 2860 2150×1500×820 3000
U21 2.5 Light Duty 0.86 2.15 4 2 2 Φ16 Φ400 10.3 2.83 5T 3350 2150×1500×920 3150
U99 0.5 Heavy Duty >1.7~2.5 0.85~1.25 5 2 2 Φ16 Φ350 9.5 2.05 5T 2276 1450×950×416 1800
U100 0.5 Overload Duty >2.5~4 1.25~2 5 2 2 Φ16 Φ400 10 2.35 5T 2450 1450×950×420 1850
Z1 1 Heavy Duty >1.8~1.9 1.8~1.9 5 2 2 Φ16 Φ350 12.22 2.524 5T 2708 1930×1050×798 2170
Z15 1.5 Medium Duty >1~1.2 1.5~1.8 5 2 2 Φ16 Φ350 13 2.35 5T 2710 2130×1250×830 2770
Z25 2.5 Light Duty >0.6~1.0 1.5~2.5 4 2 2 Φ16 Φ350 10.3 2.493 5T 2890 2330×1500×920 3150
U4 2 Heavy Duty >1.8~2.9 3.6~5.8 5 2 2 Φ18 Φ500 15 3.898 10T 3184 2410×1320×826 3070
U5 3 Medium Duty >1~1.8 3~5.4 5 2 2 Φ18 Φ500 15 4.4 10T 3301 2650×1550×900 3200
U6 5 Light Duty >0.5~1 2.5~5 3 2 2 Φ18 Φ500 10 4.62 10T 3549 2950×1900×1019 3800
U23 2 Heavy Duty >2~3 4~6 5 2 2 Φ18 Φ500 11 4.63 10T 3172 2400×1550×780 3400
U25 3 Medium Duty >1~1.7 3~5.4 5 2 2 Φ18 Φ500 11 4.868 10T 3172 2400×1748×780 3400
Sz3 3 Medium Duty 1.1~2.0 3.3~6 5 2 2 Φ19.5 Φ410 13.4 4.718 10T 3250 2800×1684×1650 3200
U7 3 Heavy Duty >1.8~2.9 5.4~8.7 5 2 2 Φ21.5 Φ610 15.3 6.3 15T 3726 2616×1700×886 3326
U8 4.5 Medium Duty >1~1.8 4.5~8.1 5 2 2 Φ21.5 Φ610 15.3 6.98 15T 3946 2956×1800×1041 3756
