Eco - Friendly High Temperature Tube Furnace Carbon Thermal Disposal And Recycling
Eco - Friendly High Temperature Tube Furnace Carbon Thermal Disposal And Recycling
Specifications
Brand Name :
Huaemw
Model Number :
HY-ZG1530E
Place of Origin :
China
MOQ :
1 PCS
Price :
Negotiable
Delivery Time :
1~12weeks
Heating Source :
Microwave & Electric
Working Temperature :
0~1550℃
Voltage :
AC 380V
Temperature Control Precision :
±0.1%
Temperature Measurement Method :
Infrared Thermometer
Static Ultimate Vacuum Degree :
≤100Pa
Description

Saturated Carbon Regeneration, Eco-friendly Carbon Thermal Disposal And Recycling

  • Product Features

Industrial Microwave Tube Furnace HY-ZG3016E is multifunctional high temperature furnaces coming with a set of standard features as follows,

HY-ZG3016E tube furnaces provide consistency in temperature, speed, performance quality and safety,

  • Applications

Active carbon is always used for waste water treatment due to super-high specific surface area, but activated carbon has a maximum adsorption limit, if saturated, activated carbon will lose the adsorption ability, while tradition thermal treatment for activated carbon regeneration is always energy consuming and cost a lot.

HY-ZG3016E can be used for saturated carbon disposal and recycling in a environment friendly way.

Microwave thermal treatment of saturated carbon can regenerate carbon with high efficiency and the outcome product can be re-used for adsorption.

  • Technical Parameters
Parameters HY-ZG3016E
Power Voltage 380V ± 10V 50Hz
Rated Power 7KW
Electrical Heating Power 3KW
Microwave
System		 Microwave
Output Power		 0.10~2.80KW
continuously adjustable
Microwave Frequency 2.45GHz
Microwave Leakage Prevention microwave leakage intensity <2mW/cm2
Thermal
Insulation System		 Tmax 1600°C
Working Temperature 0~1550°C
Heating Space
(diameter×width)		 Φ60×120mm
Temperature Control
System		 Temperature
Measurement Method		 infrared thermometer
Temperature
Measurement Range		 300~1800°C
Temperature
Control Precision		 ±0.1%
Control
System		 Auto, Manual and Isothermal Controlling Mode,
PLC+Touch Screen		 40 segments of programmable technical parameters,
data storage and export,
real-time curve data display, dynamic data display
Atmosphere System Static Ultimate
Vacuum Degree		 ≤100Pa
Atmosphere Range quick pre-vacuum pumping,
capalble of oxidizing gas, inert gas, weak reducing gas etc.
Safety System Magnetron Alarm over temperature alarm
Furnace Door Protection Alarm furnace door shutdown sensor
Overall
Dimension		 Furnace Body(L×W×H) ca.630×530×580mm
Rack(L×W×H) ca. 900×500×700mm
