HRC28-32 Hardness Mold Steel Plate Annealed Quenche DIN Standard
HRC28-32 Hardness Mold Steel Plate Annealed Quenche DIN Standard
HRC28-32 Hardness Mold Steel Plate Annealed Quenche DIN Standard
HRC28-32 Hardness Mold Steel Plate Annealed Quenche DIN Standard
Specifications
Brand Name :
CF STEEL
Model Number :
P20 1.2311 1.2312 1.2738 P20+Ni PDS-3
Certification :
ISO/Mill Certificate
Place of Origin :
China
MOQ :
5MT
Price :
To be negotiated
Payment Terms :
L/C, T/T
Supply Ability :
3000t/Month
Delivery Time :
7-30 days
Packaging Details :
standard export packing or customers' request.
Standard :
DIN,ASTM,AISI,GB,JIS
Surface treatment :
Black surface
Hardness :
HRC28-32
Test :
SGS / Ut 100% / Element Testing
Technology :
Forged or Hot Rolled
sharp :
Plate
Thickness :
10-300mm
Sample :
Free sample
Description

Hot rolled p20 alloy tool steel plate with Thickness 10-300mm
hot rolled p20 alloy tool steel plate with Thickness 10-300mm
1: 3Cr2Mo 1.2311 P20 steel introduction
AISI P20 Steel Plate Material is a versatile, low-alloy tool steel that is characterized by good toughness at moderate strength levels. The special purpose mold steel P20 steel plate is commonly used for plastic injection mold cavities and tooling and for die casting dies for zinc. P20 mold steel plate material is typically sold in the pre-hardened condition at a hardness of approximately 300 HBW.
2: P3Cr2Mo 1.2311 P20 Steel equivalent

Country USA German GB/T
Standard ASTM A681 DIN EN ISO 4957 GB/T 1299
Grade P20 1.2311 3Cr2Mo


3: P3Cr2Mo 1.2311 P20 steel chemical composition

Grade C Si Mn P S Cr Mo
P20 0.28-0.4 0.2-0.8 0.6-1 0.03 0.03 1.4-2 0.3-0.55
1.2311 0.35-0.45 0.2-0.4 1.3-1.6 0.03 0.03 1.8-2.1 0.15-0.25
3Cr2Mo 0.28-0.4 0.2-0.8 0.6-1 0.03 0.03 1.4-2 0.3-0.55


4: P3Cr2Mo 1.2311 P20 steel mechanical properties
The mechanical properties mainly include tensile strength, yield strength, elongation, area or reduction, hardness, impact value, non-metalic inclusion etc. Different heat treatment, the mechanical properties will be different, such as normalized, tempered, QT. If you want to know the properties, kindly contact the sales.

Heat treatment Normalized ; Annealed ; Quenched ; Tempered
Test Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc.
Payment terms T/T;L/C
Trade terms FOB; CIF; C&F; etc..
Delivery time 1) For abundant stock, 7-15 days.
2) For customized products, 15-30 days.

5: P3Cr2Mo 1.2311 P20 Delivery condition
For hot forged bar, usually the delivery condition is hot forged, annealed/QT rough turned/Black surface.
For hot rolled bar, usually the delivery condition is hot rolled, annealed/QT, Black surface.
For hot forged plate, usually the delivery condition is hot forged, annealed/QT, milled surface
For hot rolled plate, usually the delivery condition is hot rolled, annealed/QT, black surface.

3Cr2Mo 1.2311 P20 Hot Rolled Forged Plastic Mould Steel
HRC28-32 Hardness Mold Steel Plate Annealed Quenche DIN Standard
