TPU Hot Melt Adhesive Film High Elasticity Polyurethane for Waterproof Fabric 0.025mm-0.30mm Thickness
TPU Hot Melt Adhesive Film High Elasticity Polyurethane for Waterproof Fabric 0.025mm-0.30mm Thickness
Specifications
Thickness Range :
0.025mm-0.30mm
Hardness :
72±2（Shore A）
Operating Temperature :
130-180℃
Width Range :
5mm-1580mm
Activation Temperature :
116-157℃（Tunsing）
Brand Name :
TUNSING
Model Number :
DS8507
Certification :
ISO 9001 SGS Oeke-TEX
Place of Origin :
China
MOQ :
100yards or 100 meters
Price :
Negotation
Payment Terms :
L/C,T/T,Western Union,Western Union
Supply Ability :
40000 Square meters per day
Delivery Time :
3-5 work days after received the payment
Packaging Details :
1PC/PE FILM, 100yard/roll, 2~4roll/CTN, or it's up on the customer's option
Melt Flow Index :
10±5g/10min（ASTM D1238-04）
Description
TPU Hot Melt Adhesive Film High Elasticity Polyurethane For Waterproof Fabric
Product Overview

TPU High Elasticity Hot Melt Adhesive Film Polyurethane Hot Melt Adhesive Glue for Waterproof Fabric

Hot Melt Adhesive Film

The hot melt adhesive film described is a thermoplastic film hot melt adhesive that comes with a release paper. The hot melt adhesive film can be heated and plasticized repeatedly for bonding purposes. This particular hot melt adhesive is especially suitable for use with textiles, TPU, and PVC materials. The hot melt adhesive film possesses several notable characteristics, including a low melt flow index, a good hand feel and resilience, as well as excellent heat and cold resistance properties.

Physical Characteristics
Property Value
Colour Transparent
Release Layer Glassine Release Paper
Thickness Range 0.025mm-0.30mm
Width Range 5mm-1580mm
Proportion 1.18±0.02g/cm³
Melt Flow Index 10±5g/10min (ASTM D1238-04)
Hardness 72±2 (Shore A)
Melting Range 105-125℃ (ISO11357)
TG Temperature -27±10℃ (GB/T 19466.2-2004)
Activation Temperature 116-157℃ (Tunsing)
Recommended Bonding Conditions
First Lamination Second Implanting
Mechanical Mold Temperature: 130℃-170℃ Mechanical Mold Temperature: 140℃-180℃
Hot Pressing Time: 5-15 seconds Hot Pressing Time: 8-25 seconds
Pressure: 0.3-0.6mpa Pressure: 0.3-0.6mpa
Key Characteristics
  • Strong adhesion properties for effective bonding to various substrates including fabrics, plastics, and metals
  • Thermoplastic nature allows activation and bonding at elevated temperatures
  • Excellent flexibility and elasticity to withstand stretching and bending without compromising bond integrity
  • Suitable for applications requiring flexibility and movement
Applications
  • Textile and apparel industry for fabric bonding, seam sealing, hemming, and pocket attachment
  • Footwear manufacturing for bonding shoe components such as soles, insoles, heel counters, and toe caps
  • Automotive industry for interior trim applications including bonding fabrics, foams, and carpets
TPU Hot Melt Adhesive Film High Elasticity Polyurethane for Waterproof Fabric 0.025mm-0.30mm Thickness TPU Hot Melt Adhesive Film High Elasticity Polyurethane for Waterproof Fabric 0.025mm-0.30mm Thickness
Packing & Shipping

Packing: 100 yard in roll, 1-2 rolls in case

Shipping: 5-7 days by Express (DHL, FedEx, USP and so on)
