CNC Machining Precision Forged Steel Parts Agricultural Forging Services for Machinery Applications

Description :
Our CNC machined forged steel parts are engineered for high strength, durability, and precision performance in demanding agricultural and industrial machinery applications. Combining hot forging with CNC precision machining, we deliver components that meet exact tolerances while ensuring superior wear resistance and structural integrity.

Key Features & Benefits :

✔ Premium Material – Made from high-grade forged steel (1045, 4140, or custom alloys) for exceptional toughness.
✔ Precision CNC Machining – Tight tolerances (±0.05mm) and smooth finishes for perfect fit and function.
✔ Customizable Designs – Tailored for agricultural machinery (tractors, harvesters) and industrial equipment (excavators, conveyors).
✔ Enhanced Durability – Heat-treated for high hardness (HRC 28-50) and impact resistance.
✔ Corrosion Protection – Optional coatings (galvanization, powder coating, or plating).

Applications :

• Agricultural Machinery: Plow blades, gear shafts, tiller components, harvester parts.

• Construction/Heavy Equipment: Hydraulic cylinder rods, pivot pins, track links.

• Industrial Machinery: Gears, bushings, sprockets, custom forgings.

Product parameters :

1. Material Specifications

• Base Material:

  • Carbon Steel: 1045, 4140, 4340

  • Alloy Steel: 4140, 4340, 42CrMo4

  • Stainless Steel: 304, 316 (optional)

• Material Standards:

  • ASTM A668, DIN 17100, JIS G4105

  • RoHS & REACH compliant

2. Manufacturing Process

• Forging Process:

  • Hot forging (temperature range: 950°C-1250°C)

  • Closed-die forging for complex shapes

• CNC Machining:

  • Tolerance: ±0.05mm (standard), ±0.02mm (precision)

  • Surface roughness: Ra 0.8-3.2μm (adjustable)

3. Dimensional Specifications

• Size Range:

  • Diameter: 10mm-500mm

  • Length: up to 3000mm

  • Weight: 0.1kg-50kg (single piece)

• Shape Capabilities:

  • Shafts, gears, flanges, brackets

  • Custom complex geometries

4. Mechanical Properties

• Tensile Strength: 600-1200MPa (material dependent)

• Yield Strength: 450-950MPa

• Hardness: HRC 22-50 (heat treatable)

• Impact Test: Charpy V-notch ≥27J at -20°C

Why Choose Our Forged Steel Parts?

• Advanced Manufacturing: Hot forging + CNC machining for optimized strength & precision.

• Quality Assurance: ISO 9001 certified with material test reports (MTRs) available.

How do I place an order?

You can contact us directly with your specifications, and our team will assist you through the ordering process.
