Specifications
Brand Name :
Beihai Galvanizing
Model Number :
Non-standard
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C,T/T
Supply Ability :
No limit
Delivery Time :
60-120 working days
Packaging Details :
Like wooden box, suit for shipping and lifting
Company Type :
Manufacturing and trading
Origin :
CHINA/TAIWAN since 1990
Scope :
Equipment for a complete hot dip galvanizing plant
Advantage :
High quality
Application :
for galvanizing various steel parts
After-sales service provided :
Engineers available to service machinery overseas,Field maintenance and repair service
Condition :
New
Type :
Hot Dip Galvanizing
Coating :
Galvanizing, Zinc or Zn-Al, Hot Dip Galvanizing
Dimension(l*w*h) :
Customized
Product name :
Hot dip galvanizing line
Color :
Customized Color
Control :
Automatic/Semi-automatic
Furnace :
High velocity pulse firing system
Customers :
Worldwide
Description
Residual Heat Recovery System for Hot Dip Galvanizing Production Line
Complete Zinc Kettle Supplier Services
We supply reliable, high-performance, environmentally friendly, technological, and modern galvanizing factories with comprehensive one-stop service solutions.
Design Guidance
  • Superconducting heat pipes serve as the main heat-conducting components of waste heat recovery devices
  • Heat exchange efficiency of heating pipe-type waste heat recycling systems can exceed 98%, significantly outperforming ordinary heat exchangers
High Efficiency Heat Exchange Residual Heat Recovery System for Environmentally Friendly Hot Dip Galvanizing Line with Customized Design
Working Principle of Heating Pipes
  • The lower section functions as the flue, the upper section contains water pipes, separated by a partition board
  • During operation, flue gas flows through the waste heat recycling system flue, washing the lower end of heating pipes
  • Heating pipes absorb heat and transfer it to the upper end, where heat is released to warm the water
High Efficiency Heat Exchange Residual Heat Recovery System for Environmentally Friendly Hot Dip Galvanizing Line with Customized Design
Construction Details: Heat pipes are manufactured from steel, copper, and aluminum tubes filled with heat-conducting media, drawn to specific vacuum levels, and sealed. The heat-conducting medium consists of inorganic active metals and their compounds, exhibiting exceptional thermal activity and sensitivity.
Thermal Properties: The superconducting fluid activates at specific temperatures, transferring heat through molecular oscillation phase transition. Thermal conductivity is approximately 10,000 times greater than ordinary metals, with no heat transfer temperature decay and exceptionally rapid transfer speeds.
High Efficiency Heat Exchange Residual Heat Recovery System for Environmentally Friendly Hot Dip Galvanizing Line with Customized Design
Our Comprehensive Services
  • Zinc Kettle Design: Optimal dimension selection based on plant size, material specifications, and processing capacity
  • Plant Layout: Strategic arrangement considering land size, environmental requirements, and galvanizing processes
  • Civil Work Design: Comprehensive calculations and building drawings for steel and concrete structures
  • HDG Equipment Manufacturing: Complete galvanizing factory equipment production from essential to auxiliary systems
  • Installation & Commissioning: Professional installation services, user guidance, chemical supply, and technical adjustments
Main Equipment Overview
No. HDG Process Equipment Purpose
1 Pickling Enclosed pretreatment workshop
Acid fume treatment equipment
Pickling electric hoist/crane		 Collect acid fume
Environmental protection
Material transfer
2 Rinsing Wastewater treatment equipment Environmental protection
3 Degreasing Waste heat recycling system Energy conservation
4 Rinsing Wastewater treatment equipment Environmental protection
5 Fluxing Waste heat recycling system
Iron removal equipment		 Energy conservation
Recycling efficiency
6 Galvanizing Galvanizing furnace body
Zinc kettle
White fume fixed hood
White fume treatment equipment
Bridge crane/electric hoist		 Heating application
Zinc placement
Fume collection
Environmental protection
Material transfer
7 Cooling Cooling tower Water recycling
8 Passivation Chromium-free passivator Effective coating
9 Auxiliary Bridge crane/Flat trolley/Material rack/Transfer pit
Tank's anti-corrosion protection
Zinc ingot/Chemicals/Alloy		 Material handling
Safety assurance
Essential supplies
Service Process
  • Demand communication and analysis
  • Custom plant design and planning
  • Supply of hot dip galvanizing equipment
  • Professional assembly and commissioning
  • Supply of advanced galvanizing techniques
  • 24-hour after-sales service support
Galvanizing Training Programs
  • Comprehensive theory of hot dip galvanizing
  • Zinc ingot melting procedures and best practices
  • Zinc kettle operation and maintenance guidance
  • Fume reduction and control techniques
  • Coating problem diagnosis and treatment
  • Chemical additive adjustment and optimization
Production Line Selection Guidance
Several critical factors influence the selection of appropriate production lines and kettle sizes:
  • Available land size and facility constraints
  • Material types, sizes, and production quantities
  • Environmental protection requirements and regulations
Important Considerations: Hot dip galvanizing is not suitable for all product coatings. Some products may require alternative plating methods, necessitating different production line configurations.
Operational Commitment: Once operational, galvanizing facilities cannot be stopped arbitrarily. Zinc solutions must remain molten year-round, requiring continuous operation and substantial workload to offset costs and generate profits.
Kettle Sizing Strategy: Optimal kettle size is determined by the largest parts in highest production volume. For example, if 12m pipes represent a small portion of production while 6m steel structures dominate, we recommend against 12.5m kettles. Provide your part specifications for customized kettle design recommendations.
Why Choose Us
Beihai Galvanizing - Your tailored factory solution, worthy of your trust and investment.
Partner with us for a mutually beneficial future and sustainable business growth.
