Professional Small Stationary Asphalt Mixing Plant Energy Saving 40-320 T/H
Professional Small Stationary Asphalt Mixing Plant Energy Saving 40-320 T/H
Professional Small Stationary Asphalt Mixing Plant Energy Saving 40-320 T/H
Professional Small Stationary Asphalt Mixing Plant Energy Saving 40-320 T/H
Professional Small Stationary Asphalt Mixing Plant Energy Saving 40-320 T/H
Professional Small Stationary Asphalt Mixing Plant Energy Saving 40-320 T/H
Professional Small Stationary Asphalt Mixing Plant Energy Saving 40-320 T/H
Professional Small Stationary Asphalt Mixing Plant Energy Saving 40-320 T/H
Specifications
Brand Name :
ZOOMLINE
Model Number :
ZAP-S40-400
Certification :
CE, ISO, EAC, EMC
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
10 sets per month
Delivery Time :
about 30-40 days
Packaging Details :
40HQ container
Product name :
Hot Road Construction Plant
Capacity :
40-320t/h
Condition :
New
Power(kw) :
According to the capacity
Color :
Client's Customized
Warranty :
15 Months
Description

Asphalt Mixture Stationary Asphalt Mixing Plant Small Asphalt Plant

Product Description

ZAP-S series Stationary Batch Asphalt Mixing Plant are available from 40TPH to 320TPH, and is most popular for its high output and high performance.

Main advantages:

• Cost effective solutions for your project

• Multi-fuel burner for choose

• Environmental protection, energy saving, safe and easy to operate

• Low maintenance operation & Low energy consumption & Low emission

• Optional environmental design - sheeting and clad to customers requirements

• Rational layout, simple foundation, easy to be installed and maintenance

Control system

- Using Germany SIEMENS electrical components, it can work stably even under harsh working conditions.

- Using Japan's ORMON PLC and touch screen, which has strong data processing capability, automatic data sheet control, and can store various operational data in real time.

- All system power switches can be controlled through the control panel, which is easy to operate and easy to control.

- Multi-language compatibility, the display language can be selected according to customer preferences.

- The control cabinet is IP55 rated to meet the highest industry standards in the world.

- Container control room with thermal and acoustic insulation.

- Global remote automatic detection function.

*Plant capacity is base on standard working condition as followings:

Atmospheric pressure 760mmHg
Ambient temperature 20℃
Material passing 40mm mesh 100%
Material passing 3mm mesh 40%
Material passing 74µm ≤7%
Aggregate temperature at discharging end of drum dryer 160℃
Density of aggregate 1650kg/m3
Specific heat of aggregate 0.21kcal/kg℃
Filler content 5%
Bitumen content 5%
Sand content ≤40%
Max.aggregate size ≤40mm
Average moisture of cold aggregates ≤5%
Cycle time per batch 45s
Diesel calorific value ≥10500Kcal/kg
Heavy oil calorific value ≥9850Kcal/kg
Nature gas calorific value ≥8000Kcal/Nm3
Coal calorific value ≥5500Kcal/kg

Professional Small Stationary Asphalt Mixing Plant Energy Saving 40-320 T/HProfessional Small Stationary Asphalt Mixing Plant Energy Saving 40-320 T/H
