ZNC350 Die Sinking Machine Customized EDM Spark Cnc Electric Discharge Edm factory
ZNC350 Die Sinking Machine Customized EDM Spark Cnc Electric Discharge Edm factory
Specifications
Brand Name :
hosen
Model Number :
znc350
Place of Origin :
China
MOQ :
1
Price :
good price
Payment Terms :
T/T
Supply Ability :
5000set /per month
Delivery Time :
1-7working day
Packaging Details :
wooden box
Description

Main Feature-EDM Die Sinker-ZNC 350

1. Depth desigh for Positive and Negative coordinate processing
2. Z Equipped with High Precise Taiwan ball screw.
3. Adaptive EDM control
4. Regular high-speed lift and carry the knife blade height control
5. Spindle position control, the discharge gap detection
6. ZNC system, manual control box operation
7. Z-axis AC servo system
8. Roughness: <Ra 0.3µm
9. 3 axis DRO Minimum drive unit 5 um
ITEM ZNC350 ZNC450 ZNC540 ZNC650 ZNC750
Table Size mm 600x350 700x400 800x400 1000x600 700x450
XY Travel mm 350x250 400x350 500x400 600x500 700x600
Spindle Servo Travel mm 180+200 200+200 250+300 280+300 300+350
Max.Table Load kgs 800 1000 1300 2500 2800
Max.Electrode Load kgs 120 150 150 220 250
Max.Work Current A 50 50 75 90 90
Max.Work Speed mm3/min 300 400 500 600 600
Electrode Wear Ratio <0.2% <0.2% <0.2% <0.2% <0.2%
Best Roughness um <0.3 <0.3 <0.3 <0.3 <0.3
Oil Work Tank mm 900x500x400 1370x670x450 1400x700x500 1800x900x600 1800x900x600
