Specifications
Brand Name :
FY
Model Number :
FY-25CZ
Certification :
CE
Place of Origin :
Shanghai,China
MOQ :
1 set
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
300 sets per month
Delivery Time :
2-7 working days
Packaging Details :
export standard wooden box
Reinforcement :
1-4 layers wire/4 SP
crimping range :
6-25 mm/1 inch
quantity of dies :
7 sets for standard support
accuracy :
0.1 cm
system pressure :
300bar
motor power :
1.5kw
voltage :
12v/24v(optional),depend on cliend demand
crimping force :
0.6Mt
Product Name :
12V/24V With 7 Dies Blue Color Car Loading 1 Inch Braided Hose Crimper Battery Drive Hydraulic Hose Press Machine/Hose Crimping Machine 6-25mm
Description

12V/24V With 7 Dies Blue Color Car Loading 1 Inch Braided Hose Crimper Battery Drive Hydraulic Hose Press Machine/Hose Crimping Machine 6-25mm

Product Description

Introducing our 12V/24V Hydraulic Hose Crimping Machine, designed for efficiency and versatility in automotive applications. This battery-driven crimper is capable of handling 1-inch braided hoses with a size range of 6mm to 25mm. Equipped with 7 dies, this machine ensures precise and reliable crimping every time.

Key Features

  • Dual Voltage Operation: The machine operates at both 12V and 24V, allowing for flexibility and ease of use in various environments.
  • Versatile Hose Compatibility: Designed to crimp hoses ranging from 6mm to 25mm, making it suitable for a variety of applications.
  • 7 Crimping Dies: Comes with seven different dies to accommodate various hose sizes, ensuring versatility and precision.
  • Compact and Portable: Lightweight design makes it easy to transport, perfect for on-site repairs and mobile operations.

Advantages

  1. Efficient Crimping: The automatic operation reduces crimping time, enhancing productivity and workflow.
  2. Durable Design: Built from high-quality materials, this crimper is designed for longevity and reliable performance in demanding conditions.
  3. User-Friendly: The intuitive design allows operators of all skill levels to use the machine effectively, ensuring consistent results.
  4. Enhanced Visibility: The blue color of the machine not only adds aesthetic appeal but also makes it easy to identify in a busy workspace.
Model FY-25CZ Pipe Crimping Machine
Crimping Range 6-25(mm)/1inch
Crimping Force 600(T)/0.6MT
Hose Size 1/4-1(inch)/6-25mm hose inner diameter
Max. Opening 114(mm)
Die Sets 7
output volume of pump
4L
System Pressure 30(Mpa)/300 Bar
Accuracy 0.01(mm)/0.1cm
the max open tolerance
30 ±mm
Standard Voltage 12V/24(V) depend on client demand
Motor Power 1.5(KW)
Length 600(mm)/60 cm
Width 450(mm)/45 cm
Height 350(mm)/35 cm
Weight 52(KG)/machine's net weight

12V / 24V 7 Dies Blue Color Car Loading 1 Inch Braided Hose Crimper Battery Drive Hydraulic Hose Press Machine 6-25mm

12V / 24V 7 Dies Blue Color Car Loading 1 Inch Braided Hose Crimper Battery Drive Hydraulic Hose Press Machine 6-25mm

12V / 24V 7 Dies Blue Color Car Loading 1 Inch Braided Hose Crimper Battery Drive Hydraulic Hose Press Machine 6-25mm

12V / 24V 7 Dies Blue Color Car Loading 1 Inch Braided Hose Crimper Battery Drive Hydraulic Hose Press Machine 6-25mm

12V / 24V 7 Dies Blue Color Car Loading 1 Inch Braided Hose Crimper Battery Drive Hydraulic Hose Press Machine 6-25mm

12V / 24V 7 Dies Blue Color Car Loading 1 Inch Braided Hose Crimper Battery Drive Hydraulic Hose Press Machine 6-25mm

12V / 24V 7 Dies Blue Color Car Loading 1 Inch Braided Hose Crimper Battery Drive Hydraulic Hose Press Machine 6-25mm

12V / 24V 7 Dies Blue Color Car Loading 1 Inch Braided Hose Crimper Battery Drive Hydraulic Hose Press Machine 6-25mm

NOTE
• " * " for non standard die sets
• Customized die sets with different shape size ia available
• Voltage 12V/24V is available

Crimping Range
6-25mm(1/4''-1''inner diameter of hose)
The Largest Crimping Pressure
600T
accurcy
0.01mm
Dimension
0.6m*0.45m*0.35m(0.1 m³)
Maximum open diameter
114mm
dies
7 sets
Item No.of dies
length 60mm(15,19,23,26);Length 70mm(31,36,41);Length 80mm(47)
Output volume of pump
4L
Rated pressure
30Mpa/300 BAR
Work efficiency
200pcs/h
Weight
52kg/machine's net weight
packing dimension
620*470*370mm

OPTIONAL
• Quick Change Tool
• Quick Change Die Set Rack
• Car installing unit


► FORGED CYLINDER
One piece structure, prevent oil leackage problem, save oil transfer time, increase productivity

► MICROMETER
FY25CZ is with high accuracy dial, 0.01mm.

12V / 24V 7 Dies Blue Color Car Loading 1 Inch Braided Hose Crimper Battery Drive Hydraulic Hose Press Machine 6-25mm

► DIE SET REFERENCE SHEET
This sheet tells you how to choose proper die set for different crimping size

12V / 24V 7 Dies Blue Color Car Loading 1 Inch Braided Hose Crimper Battery Drive Hydraulic Hose Press Machine 6-25mm

► WIDE USAGE
FY-25CZ Crimping machine can be used in a mobile van which can supply 12V/24V power.
For high pressure oil rubber hose assmbly crimping, low pressure water or air hose pressing, steel tube
swaging, wire rope pressing, lock device making, etc.

12V / 24V 7 Dies Blue Color Car Loading 1 Inch Braided Hose Crimper Battery Drive Hydraulic Hose Press Machine 6-25mm
