2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
Specifications
Brand Name :
FanYing
Model Number :
FY-51BY
Place of Origin :
China,Shanghai
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
10000 SETS PER MONTH
Delivery Time :
3 WORKING DAYS
Packaging Details :
STANDARD WOODEN BOX
Weight :
310 kg
system pressure :
315 bar
Material :
Rubber/Hose
Name :
Rubber Hose Crimping Machine
Warranty :
1 Year
Crimping Force :
600T/0.6MT
Type :
Crimping Machine/crimper
Product Name :
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
Color :
Blue or as client demand
Description
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies

2 Inch 600T Rubber Hose Crimping Machine (Blue) — 6–51 mm, 220V/380V, 10 Interchangeable Dies

Product Overview

The 2 Inch 600T Rubber Hose Crimping Machine is a high-performance crimper built for workshops that need fast, reliable and repeatable rubber hose assemblies. Designed for automotive hydraulic repairs, industrial maintenance and oil/hose production support, it suits customers in the USA, Europe and Southeast Asia who require consistent crimps for leak-resistant performance. With a 6–51 mm crimping range, 600T crimping force and 10 interchangeable dies, this rubber hose crimping machine delivers strong, uniform crimp profiles for everyday shop efficiency and dependable field results.

Product Features & Characteristics

  • Crimping Range (6–51 mm / up to 2 inches): Covers a wide set of medium hose sizes commonly used in hydraulic and automotive systems.
  • 600T Crimping Force: Provides strong compression for secure hose-to-fitting connections, helping reduce leakage risk.
  • Electric-Hydraulic Stability: Smooth hydraulic action supports uniform crimping for consistent results across production batches.
  • 10 Interchangeable Dies: Multiple die options included to match different hose/fitting sizes and speed up job changeovers.
  • Blue High-Model Industrial Finish: Durable, workshop-ready exterior designed for frequent use in industrial environments.
  • Adjustable Control for Better Workflow: Designed to simplify setup and maintain repeatable crimp settings.
  • Safety Protections: Emergency stop and hydraulic pressure protection help safeguard operators and equipment.

Advantages

  • Stronger, More Reliable Assemblies: The 600T force helps achieve secure crimps, improving system durability in high-pressure applications.
  • Faster Shop Turnaround: Quick die setup improves productivity for hydraulic/car repair shops and oil/hose service teams.
  • Wide Adoption Across Markets: 220V/380V voltage options make it easier for customers in the USA and Europe to install and operate.
  • Reduced Rework & Downtime: Consistent crimp formation helps minimize rejects, improving overall cost efficiency.

  1. 2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies

2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
2 Inch 600T Rubber Hose Crimping Machine Higher Model Blue Color 220v/380v Voltage With 6-51mm Range And 10 Interchangeable Dies
Technical Specifications
Specification Value
Crimping Range 6-51 mm
Crimping Force 600 T
Quantity of Dies 10 sets
Accuracy 0.01 mm
System Pressure 31.5 MPa
Motor Power 3 kW
Voltage Options 220V/240V/380V/415V
Work Efficiency 200 pcs/h
Maximum Open Diameter 114 mm
Machine Dimensions 860 * 640 * 1300 mm
Net Weight 310 kg
Warranty 1 Year
Operational Advantages
  • Enhanced Efficiency: Strong crimping force and quick-change dies increase workshop productivity
  • Cost-Effective Solution: Accommodates multiple hose sizes, reducing equipment investment
  • User-Friendly Operation: Intuitive design requires minimal training for technicians
  • Dependable Performance: Heavy-duty construction minimizes operational interruptions
  • Multi-Industry Application: Suitable for hydraulic repair, automotive service, and oil industries
Industrial Applications

The FanYing FY-51QY Electric Hydraulic Rubber Hose Crimping Machine serves multiple industrial sectors including automotive, construction, machinery, mining, aviation, railway, chemical, and oil & gas industries. Ideal for crimping hydraulic and pneumatic rubber hoses, fuel hoses, oil pipes, and various industrial rubber hose applications.

Product Support & Customization

Manufactured in Shanghai, China with comprehensive 1-year warranty. Complete technical support available 24/7 with trained technicians providing onsite installation, training, maintenance, and repair services.

Frequently Asked Questions
What sizes of hoses can this machine crimp?
The rubber hose crimping machine can handle hoses ranging from 6mm to 51mm, making it suitable for various rubber hose applications.
How does the fast change mould system enhance workflow?
The fast change mould system allows for quick swaps between dies, significantly reducing downtime and enhancing workflow efficiency in busy settings.
What is the maximum crimping force of this machine?
This machine offers an impressive crimping force of 600 tons, capable of securely crimping high-pressure rubber hoses.
Is this machine suitable for heavy-duty applications?
Yes, designed for high crimping force, this machine is ideal for heavy-duty applications in hydraulic and automotive fields.
How durable is the construction of this machine?
Constructed from high-quality materials, the machine is built for longevity and reliability, even with continuous use in demanding environments.
Professional-Grade Performance: The 2 Inch 600T Rubber Hose Crimping Machine is an essential tool for professionals in the hydraulic and automotive industries. With its high crimping force, versatile design, and user-friendly operation, it boosts productivity and ensures reliable hose management. Invest in this high-performance rubber hose crimping machine to meet your operational demands and achieve outstanding results in your crimping applications!
