2 Inch Hydraulic Hose Crimping Machine with 640T Crimping Force, 31.5Mpa System Pressure and Double Conical Master Die
2 Inch Hydraulic Hose Crimping Machine with 640T Crimping Force, 31.5Mpa System Pressure and Double Conical Master Die
2 Inch Hydraulic Hose Crimping Machine with 640T Crimping Force, 31.5Mpa System Pressure and Double Conical Master Die
2 Inch Hydraulic Hose Crimping Machine with 640T Crimping Force, 31.5Mpa System Pressure and Double Conical Master Die
2 Inch Hydraulic Hose Crimping Machine with 640T Crimping Force, 31.5Mpa System Pressure and Double Conical Master Die
2 Inch Hydraulic Hose Crimping Machine with 640T Crimping Force, 31.5Mpa System Pressure and Double Conical Master Die
Specifications
Brand Name :
MENSION
Model Number :
MS-E130
Certification :
CE RoHS
Place of Origin :
CN
MOQ :
1 Set
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1000 Sets Per Month
Delivery Time :
2 - 7 Working Days
Packaging Details :
One Plywood For One Set
Price :
Contact Us
Crimping Range :
14 - 87mm
Hose Size :
2inch 4SH
Die Sets :
10
Color :
Blue
Max. Opening :
25mm
Crimping Force :
640T
Product Name :
MS - E130 Crimping Machine
Application :
Workshop
System Pressure :
31.5Mpa
Power :
3KW / 4KW
Size :
630*450*560mm
Weight :
190Kg
Description
2 Inch Hydraulic Hose Crimping Machine P20 Finn Power Hose Pipe Pressing Machine
HYDRAULIC HOSE CRIMPING PRESS MACHINE MS-E130

For hose crimping machine MS-E130 we supply brand new type and used second hand machine if possible. A high pressure hydraulic hose crimping machine can be used for stainless steel braided rubber hose or a low pressure industrial hose crimping.

ADVANTAGES
  • Compact structure with light weight
  • New and advanced oil transfer channel
  • Quick opening speed
  • Die sets hardness 58-63 HRC
  • Double conical master die
TECHNICAL DATA
Model MS - 130 Crimping Machine
Crimping Range 14 - 87 (mm)
Crimping Force 640 (T)
Hose Size 1/4 - 2 (inch) 4SH
Max. Opening 25 (mm)
Die Sets 10
Die Set Type 130
System Pressure 31.5 (Mpa)
Accuracy 0.01 (mm)
Control MS
Standard Voltage 220 (V) / 380 (V)
Motor Power 3 (KW) / 4 (KW)
Length 630 (mm)
Width 450 (mm)
Height 560 (mm)
Weight 190 (KG)
2 Inch Hydraulic Hose Crimping Machine with 640T Crimping Force, 31.5Mpa System Pressure and Double Conical Master Die
130 CRIMPER DIE SETS
Die No. Crimping Range Length
6* 6 - 8 mm 35
8* 8 - 10 mm 35
10* 10 - 12 mm 35
12* 12 - 14 mm 35
14 14 - 16 mm 60
16 16 - 20 mm 60
20 20 - 22 mm 60
22 22 - 26 mm 60
26 26 - 30 mm 70
30 30 - 38 mm 70
38 38 - 46 mm 70
46 46 - 54 mm 80
54 54 - 64 mm 80
64 64 - 69 mm 80
69* 69 - 76 mm 100
NOTES
  • Customized die sets are available
  • Special voltage 110V, 208V, 240V, 415V are available
  • * for non standard die sets
OPTIONAL ACCESSORIES
  • Quick Change Tool
  • Quick Change Die Set Rack
  • UC control
  • Foot Pedal
  • Pressure Gauge
  • Normal Rack
HIGH QUALITY DIE SETS AND UNIQUE DOUBLE BEVEL MASTER DIE DESIGN
2 Inch Hydraulic Hose Crimping Machine with 640T Crimping Force, 31.5Mpa System Pressure and Double Conical Master Die
OPERATE PANEL, EASY TO LEARN CRIMPING
2 Inch Hydraulic Hose Crimping Machine with 640T Crimping Force, 31.5Mpa System Pressure and Double Conical Master Die
CLEAR SHEET TO TEACH HOW TO CHOOSE PROPER DIE SETS
2 Inch Hydraulic Hose Crimping Machine with 640T Crimping Force, 31.5Mpa System Pressure and Double Conical Master Die
HIGH ACCURACY DIAMETER CONTROL DEVICE
2 Inch Hydraulic Hose Crimping Machine with 640T Crimping Force, 31.5Mpa System Pressure and Double Conical Master Die
