Max shear force 250ton blade length 800mm Q15-2500 Hydraulic Gantry Plate Shear Machine
Max shear force 250ton blade length 800mm Q15-2500 Hydraulic Gantry Plate Shear Machine
Max shear force 250ton blade length 800mm Q15-2500 Hydraulic Gantry Plate Shear Machine
Max shear force 250ton blade length 800mm Q15-2500 Hydraulic Gantry Plate Shear Machine
Max shear force 250ton blade length 800mm Q15-2500 Hydraulic Gantry Plate Shear Machine
Max shear force 250ton blade length 800mm Q15-2500 Hydraulic Gantry Plate Shear Machine
Specifications
Brand Name :
Dalongkai
Model Number :
Q15-2500
Certification :
ISO9001,CE
Place of Origin :
China
MOQ :
1
Price :
$28571-$30000 per set
Payment Terms :
L/C, T/T
Supply Ability :
5 sets per month
Delivery Time :
50-60 days
Packaging Details :
nude packing
Model NO. :
Q15-2500
Max Shear Force :
250(Ton)
Blade Length :
800(mm)
Max Cutting Specifications :
30*500(mm)
Shearing Frequency :
4-7(Times/Min)
Motor Power :
30(Kw)
Driven Type :
Hydraulic
Voltage :
380V,50HZ
Automatic Grade :
Semi-Automatic
Production Capacity :
5 Sets/Month
Description
Q15-2500 Gantry Plate Shear Machine
This hydraulic gantry plate shear machine is designed for processing various metal plates, cutting them into materials of different specifications. It effectively replaces flame cutting processes, significantly reducing operational costs while improving efficiency in sheet metal processing applications.
Product Information
Model Number:
Q15-1200~Q15-3150
Certification:
ISO9001,CE
Place of Origin:
Jiangsu P.R. China
Product Name:
Gantry plate shear
Condition:
New
Application:
Scrap metal
Nominal Force:
250Tons
Driven Type:
Hydraulic
Power:
30kW
Voltage:
380V,50HZ, Customized
Color:
Customized
Automatic Grade:
Semi-Automatic
Technical Specifications
Model Shearing Force (ton) Blade Length (mm) Max. Cutting Material (mm) Shearing Frequency (times/min) Motor (KW)
Q15A-1200 120 600 18*500 4-7 15
Q15A-1600 160 600 20*500 4-7 18.5
Q15A-2000I 200 600/800 25*500 4-7 22
Q15A-2500I 250 600 30*500 4-7 22
Q15A-2500II 250 800 30*700 4-7 2*15
Q15A-3150 315 800 30*700 4-7 45
Q15A-4000 400 800 35*700 4-7 2*22
Q15A-5000 500 900 40*800 4-7 2*45
Q15B-1600 160 1200 16/12*1000 4-7 18.5
Q15B-2000 200 1200 18/16*1000 4-7 22
Q15B-2500I 250 1200/1600 25/20*1000 4-7 2*18.5
Q15B-3150 315 1200 30/25*1000 4-7 2*18.5
Product Images
Max shear force 250ton blade length 800mm Q15-2500 Hydraulic Gantry Plate Shear Machine Max shear force 250ton blade length 800mm Q15-2500 Hydraulic Gantry Plate Shear Machine Max shear force 250ton blade length 800mm Q15-2500 Hydraulic Gantry Plate Shear Machine
Commercial Terms
Minimum Order:
1 Set
Price:
Negotiable
Payment Terms:
30% T/T In Advance
Supply Ability:
5 sets/month
Delivery Time:
50-60 days
Packaging:
Seaworthy packing
After-sales Service:
Engineers available for overseas service
