CK61100 CNC Flat Bed Lathe Automatic Fanuc Siemens Mitsubishi Control System
CK61100 CNC Flat Bed Lathe Automatic Fanuc Siemens Mitsubishi Control System
CK61100 CNC Flat Bed Lathe Automatic Fanuc Siemens Mitsubishi Control System
CK61100 CNC Flat Bed Lathe Automatic Fanuc Siemens Mitsubishi Control System
Specifications
Brand Name :
HR
Model Number :
CK61100
Certification :
CE
Place of Origin :
CHIAN
MOQ :
1 SET
Price :
19999USD
Payment Terms :
L/C, T/T
Supply Ability :
100SETS/month
Delivery Time :
30 working days
Packaging Details :
Plywood Box
Voltage :
3 PHASE 380V 50HZ
Automatic grade :
Automatic
Power(w) :
11/15kw
Condition :
New
Max. swing diameter :
1000mm
Cnc or not :
CNC
Type :
Horizontal,TURNING CENTER
After-sales service provided :
Engineers available to service machinery overseas,Online support
Warranty :
1 Year
Spindle bore :
105mm
Description
Product Description
CNC Lathe use
The machine tool is automatically controlled by the CNC control system to perform various inner holes, outer circles, conical surfaces, arc surfaces, and thread turning. It is especially suitable for rough and fine machining of shafts and disc parts in small and medium batches, with a degree of automation High, simple programming, high precision and other advantages.
CK61100 CNC Flat Bed Lathe Automatic Fanuc Siemens Mitsubishi Control System
CK61100 CNC Flat Bed Lathe Automatic Fanuc Siemens Mitsubishi Control System
CK61100 CNC Flat Bed Lathe Automatic Fanuc Siemens Mitsubishi Control System
Left Elevation
Front Elevation
Right Elevation
CNC Lathe Features
1. A high strength, widening the crriage, suitablefor heavy cutting
2. Four position electricturret
3. Frequency conversion stepless speed regulation
4. Standard configuration: manual chuck
5. Optional configuration:hydraulic chuck
CK61100 CNC Flat Bed Lathe Automatic Fanuc Siemens Mitsubishi Control System
Max. swing over bed(mm)
Φ1000
Max. swing dia. over cross slide(mm)
Φ630
Max.processing length(mm)
1000/1500/2000/3000
Max.processing diameter(mm)
Φ1000
maximum diameter of bar(mm)
Φ630
chuck
630 3jaw or 800 4 jaw
The spindle terminal structure
D11
Diameter of spindle bore(mm)
Φ105
The taper of spindle front-end
1:20
Spindle speeds series
Four files manually/Hydraulic four files
Spindle speeds(r/min)
30-84/53-150/125-350/300-835
X/Z axis travel(mm)
MM350/(1000/1500/2000/3000)
X/Z axis lead screw diameter × pitch(mm)
φ3208/φ5010
X/Z fast moving(m/min)
4/6
Tool post form
Electric vertical
number of work position
4
Tool bar section (turning/boring)
32/40
Sleeve diameter / stroke(mm)
Φ100/250
Sleeve inside the hole taper
MT6
Sleeve driven form
manual
Tailstock body movement form
manual
main motor(kw)
11
Spindle motor torque(nm)
48
Motor of Z axis X(kw)
1.5/2.3
X/Z nm
10/15
Coolant motor power
125w
power capacity
15KVA
Bed saddle layout
Flat bed
Guide form
Harden guide way(＞ HRC50)
Machine weight
4300/4700/5500/6500kg
length × width × height
( 3400/3900/4400/5400 )/1900/2000 mm
