Industrial Air Handling Units AHU vortex module type unit designed to serve as cooling and heating source in semi centralized systems
Industrial Air Handling Units AHU vortex module type unit designed to serve as cooling and heating source in semi centralized systems
Specifications
Model Number :
HFW-560HA1
Fan type :
Axial-flow low-noise fan
MOQ :
1pc
Delivery Time :
Negotiate
Power supply :
380V/3N~/50Hz
Payment Terms :
T/T
Nominal cooling capacity(kw) :
560.0
Nominal heating input total power(kw) :
176.4
Nominal refrigeration input total power(kw) :
172.3
Dimension(mm) :
4700*2280*2540
Price :
Negotiate
Nominal Heating capacity(kw) :
605.0
Supply Ability :
20000PCS/years
Model :
HFW-560HA1
Place of Origin :
China,Beijing
Net Weight(kg) :
5350
Certification :
CE
Brand Name :
Holtop
Refrigerant type :
R410A
Packaging Details :
Carton
Description
Industrial Air Handling Units AHU Vortex Module Type
The vortex module-type air-cooled chilled water (heat pump) unit is designed to serve as cooling and heating source in semi-centralized systems. This advanced modular technology utilizes air as the cooling and heating medium, functioning as integrated central air conditioning equipment that serves as both cooling/heating source and combined unit.
System Integration
Designed to work with fan coil units, cabinet-type, ceiling-mounted air handling units, and fresh air units to form efficient semi-centralized air conditioning systems.
Key Features
  • Modular Combination & Hierarchical Startup: Flexible modular design without main/secondary machine distinction. Supports up to 16 units per group with hierarchical startup to reduce current impact on power grids.
  • Intelligent Defrosting: Multi-variable detection for precise frost determination and optimal defrost timing. Dual-system design enables interval defrosting with manual override for harsh conditions.
  • Flexible Application: Easy unit expansion suitable for phased investment. Compact size allows independent transport and installation without special equipment or dedicated machine rooms.
  • Safe Operation Control: Multiple safety protection functions with intelligent multi-variable monitoring for efficient, stable operation.
  • Fault Backup Operation: Dual-compressor design ensures continued operation if one compressor fails, maintaining system functionality.
Technical Specifications
Rated Voltage Three-phase 380V/3N~
Rated Frequency 50Hz
Power Supply Voltage ±10% of rated voltage
Storage Conditions Environmental temperature: -28 to 85℃
Control Method Remote controller
Fan Type Axial flow low-noise fan
Operating Range
Operating Condition Outdoor Ambient Temperature Outlet Water Temperature
Cooling 15℃ ≤ Temperature ≤ 48℃ 5℃ ≤ Temperature ≤ 15℃
Heating -15℃ ≤ Temperature ≤ 21℃ 40℃ ≤ Temperature ≤ 50℃
Model Specifications
Model HFW-420HA1 HFW-560HA1 HFW-840HA1 HFW-980HA1 HFW-1120HA1
Nominal Cooling Capacity (kW) 420.0 560.0 840.0 980.0 1120.0
Nominal Heating Capacity (kW) 454.0 605.0 908.0 1059.0 1210.0
Refrigeration Input Power (kW) 129.2 172.3 258.4 301.5 344.6
Heating Input Power (kW) 132.4 176.4 264.8 308.8 352.8
Compressor Quantity 3 4 6 7 8
Nominal Water Flow Rate (m³/h) 72.2 96.3 144.4 168.5 192.6
Dimensions (L*W*H mm) 3540*2280*2540 4700*2280*2540 7080*2280*2540 8240*2280*2540 9400*2280*2540
Weight (kg) 4020/4160 5350/5540 8040/8320 9370/9700 10700/11080
Important Notes

1. Nominal cooling capacity test conditions: water flow rate 0.172 m³/(h*kW), outlet water temperature 7°C, outdoor ambient temperature 35°C.

2. Nominal heating capacity test conditions: water flow rate 0.172 m³/(h*kW), outlet water temperature 45°C, outdoor dry/wet bulb temperature 7/6°C.

3. Modular unit combinations require on-site fabrication of total water piping (not provided by factory).

4. Units can be combined in groups of 1-16 units using same or different module units.

5. Control accessories must be ordered separately and include remote controller, user manual, and connection cables.
