Commercial 15K Lumen Laser Projector for Stadium Events with HDBaseT Output
Commercial 15K Lumen Laser Projector for Stadium Events with HDBaseT Output
Commercial 15K Lumen Laser Projector for Stadium Events with HDBaseT Output
Commercial 15K Lumen Laser Projector for Stadium Events with HDBaseT Output
Commercial 15K Lumen Laser Projector for Stadium Events with HDBaseT Output
Commercial 15K Lumen Laser Projector for Stadium Events with HDBaseT Output
Specifications
Brand Name :
SMX/ODM
Model Number :
MX-X15000U
Certification :
CE&ROHS
Place of Origin :
China
MOQ :
1 set
Price :
USD7950/set-USD8850/set
Payment Terms :
T/T, Western Union,Paypal
Supply Ability :
10000 sets per month
Delivery Time :
5-8 working days
Packaging Details :
Carton package/Flight case optional
Model :
MX-X15000U
Light source :
Laser
Brightness :
15000
Native Resolution :
WUXGA (1920 x 1200)support 4K
Zoom/Focus :
Powered
Screen size :
50-500 inch
Display Technology :
Liquid Crystal Display
Aspect Ratio :
Native:16:10 Compatible: 4:3/16:9
Lens :
optioanl
Description

Commercial 15K Lumen Laser Projector for Stadium Events with HDBaseT Output

The MX-X15000U 15000lumen 3LCD Laser projector is ideal for large-scale outdoor projection, building mapping, ancient citylight shows, and scenic spot creation with ultra-high brightness.

Commercial 15K Lumen Laser Projector for Stadium Events with HDBaseT Output

Key Features:

15,000 Lumens Laser Light Source – Ensures vivid, high-contrast visuals even in brightly lit environments, making it ideal for auditoriums, outdoor events, and large-scale installations.

4K UHD / WUXGA Resolution – Provides sharp, detailed imagery with support for HDR, enhancing color accuracy and dynamic range.

Long-Lasting Laser Engine – Offers up to 20,000 hours of maintenance-free operation, significantly reducing downtime and cost of ownership compared to traditional lamp-based projectors.

Flexible Installation Options – Supports motorized lens shift, zoom, and interchangeable lenses (short-throw to long-throw), enabling versatile setup in complex spaces.

Professional Connectivity & Control – Equipped with HDMI 2.0, HDBaseT, 3G-SDI, and network control (Crestron, AMX, PJLink) for seamless integration into AV systems.

Edge Blending & Stacking – Allows multi-projector configurations for immersive displays or brightness boosting in giant-screen applications.

Durable & Quiet Operation – Features a sealed optical engine for dust resistance and advanced cooling for near-silent performance (<35dB).​

Parameters:

　 Model MX-X15000U
Key parts PJ Lens optional
　 Light source Laser
　 Mainchip Topaz Prime PWC895
　 Sony IC CXD3553+CXA3832(1+3)
Brightness Brightness
( Ansi Lumens )		 15000lm
Overall Spec 　 　
Panel Display Panel 3x0.76”
Display Technology Liquid Crystal Display
Native Resolution WUXGA (1920 x 1200)
Light source
Life time		 Normal mode 20000hrs
ECO mode 20000hrs
Projection
Lens		 Zoom/Focus Powered
Throw Ratio(16:10) 1.30-3.02
F F1.7~2.0
f 21.8-49.8
Zoom Ratio ‘2.3
Screen size
(Performance
guarantee range)		 50-500 inch
(80-200 inch)
Lens Shift V 50%,-10%
Lens Shift H ±20%
CR Contrast Ratio(Min) 100000:1
Noise Noise(dB) Normal(90%): 35dB
ECO1(75% ): 32dB
ECO2(45% ): 32dB
Uniformity Uniformity(Actual Min)
-JISX6911		 90%
AR Aspect Ratio Native:16:10
Compatible: 4:3/16:9/normal
Terminal(I/O port) 　 　
Input VGA *1
HDMI 1.4(IN) *2
USB-A *1(5V/1.5A)
USB-B *1(Display)
RJ45 *1(Display)
DVI-D,SDI *1,*1(optional)
HD BaseT *1
Video N/A
Audio in
(mini jack,3.5mm)		 *1 (VGA/DVI-D share)
Output VGA *1
HDMI 1.4(OUT) *1
Audio out
(mini-jack,3.5mm)		 *1
Control RS232 *1
RJ45 *1 (Control)
USB-B *1 (For upgrade)
Wired Remote(IN) *1
Wired Remote(OUT) *1
Audio Speaker N/A
Cooling Dust filter free Closed internal circulation design
Power
Consumption		 Power Requeirements 100~240V@ 50/60Hz
Power Consumption
(Boost) (Max)		 850
Power Consumption
(Normal) (Max)		 750
Power Consumption
(ECO1) (Max)		 650
Power Consumption
(ECO2) (Max)		 450
ECO Standby Mode
Power Consumption		 <0.5W
Temp.&Humidity Operating Temp. 5 to 40deg.C
Operating Thumidity. 20-80%
Store Temp. ‘-10 to 50deg.C
Store Humidity. 20-80%
Other Functions 　 　
Keystone Keystone Correction V: ±30°
H:±30°
Pincushion/Barrel Correction
6 Corner Geometry correction
Grid ImageTune correction
OSD Languages 26 languages: English, German, French, Italian, Spanish, Polish, Swedish, Dutch ,Portugese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian, Arabic, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazak,Vietnamese,Thai, Farsi
LAN Control LAN Control-RoomView
(Crestron)		 Yes
LAN Control-AMX Discovery Yes
LAN Control-PJ Link Yes
Scanning
Frequency		 H-Synch Range 15~100KHz
V-Synch Range 24~85Hz
Display Resolution Computer Signal Input VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K@30Hz
Video Signal Input 480i, 480p, 576i, 576p, 720p, 1080i and 1080p
SW setting Auto Setup INPUT SEARCH,AUTO PC,
Blank Yes
Suspend Yes(5miniutes no singnal as default)
Picture mode Dynamic,Standard,Cinema,Colorboard,DICOM,blackboard(green)
Cooling time 0s,30s,Normal
Closed caption N/A
High altitude Yes(1400~3650m)
Auto Ceiling Yes
D-Zoom 1~33
Others 360° projection 360° all-round installation
Edge Blending Yes
Dimension&Weight MAX Dimensions
(WxHxD mm)		 600*218*503
　 Net. Weight (KG) ~24kg
　 Packaging Box Dimensions
(WxHxD mm)		 725*622*350
　 Gross. Weight (KG) ~28.5kg
Accessory Manual Languages Chinese,English
　 Standard Accessaries Power cord(3m,Black),
Remote control&RC Battery

Commercial 15K Lumen Laser Projector for Stadium Events with HDBaseT Output

Company profile:

SMX – Professional Immersive Visual Solution Manufacturer & Exporter

We are a national high-tech enterprise specializing in the R&D and manufacturing of high-end projection technology. Since our inception, we have been committed to providing professional visual display solutions for global clients.

Core Technologies & Products:

3LCD Projection Technology: Utilizing advanced 3-chip LCD technology to ensure consistent color and white brightness, delivering accurate color reproduction and smooth images ideal for prolonged viewing and detailed presentations.

Laser Projection Series: Full laser projectors feature an ultra-long lifespan of over 20,000 hours, stable brightness, low maintenance, and support 24/7 continuous operation, making them suitable for museums, boardrooms, and commercial installations.

Large-Venue Laser Projectors: Designed specifically for immersive experiences and 3D Mapping, these high-brightness (up to tens of thousands of lumens) projectors offer high contrast and edge-blending capabilities. They are engineered for architectural projection, cultural tourism nightscapes, stage performances, and virtual simulation projects.

Our Mission:
To reshape spatial storytelling and create unforgettable visual experiences through innovative projection technology.
