Specifications
Brand Name :
SMX
Model Number :
SX400EH
Certification :
CE/ROHS
Place of Origin :
China
MOQ :
1 piece
Price :
negotiation
Payment Terms :
T/T or western Union
Supply Ability :
3,000pcs per month
Delivery Time :
5-10 Days
Packaging Details :
Packed in carton firstly, and then reinforced with Edge board and plastic bag for outer packing
Product Name :
Motorized Tab Tensioned Screen
Screen Fabric :
HD Flexible White
Housing Material :
Aluminum
Size :
Custom Sizes
Motor Type :
Silent Tubular Motor
Voltage :
110-240V
Remote Controller :
RF/IR/12V Trigger
Color :
White
Viewing Area(mm) :
8854*4980
Description

Large Event Motorized Tab-Tensioned Screen with Heavy-duty Tubular Motor designed for

Large-scale Presentations

Production description

Having the capability to design and manufacture commercial-grade large stage screens with a high level of precision and expertise is a crucial attribute that differentiates SMAX from the competition. SMAX’s Large Stage motorized screens are an iconic product featuring an unrivalled level of quality and design features. The high-intensity extra-large aluminum alloy roller allows it to remain rigid and straight up to 10m span, which contributes greatly to keeping the screen flat even at large sizes. The internal structure is equipped with self-lubricating supports and special shock absorbent parts to effectively reduce noise and vibration to a minimum.

Large Event Motorized Tab-Tensioned Screen with Heavy-duty Tubular Motor designed for Large-scale Presentations

Features of Electric Screen

• Sizes: 400” – 500” diagonal
• Installation Options: Wall Mount / Ceiling Mount
• Control Options: IR / RF / RS485 + Dry Contact Control / 3-12 Voltage Trigger Control / Central Control
• Colour: Black
• High-intensity Wood Casing

Format Model Inch View AreaWxH(mm) Housing Size LxWxH(mm) A1 A2 A3 Packing Size LxWxH(mm)
4:3 SX200V 200 4060x3050 2060x130x150 60 60 100 2180x220x170
SX250V 250 5080x3810 2380x150x200 60 60 100 2500x220x170
SX300V 300 6100x4570 2790x200x230 100 60 100 2910x220x170
SX400V 400 8130x6100 3400x250x300 100 60 100 3520x220x170
16:9 SX200H 200 4430x2490 2060x130x150 60 60 400 2510x220x170
SX250H 250 5540x3110 2380x150x200 60 60 400 2680x220x170
SX300H 300 6640x3740 2790x200x230 100 60 400 2490x220x170
SX400H 400 8860x4980 3400x250x300 100 60 400 3130x220x170

Main applications

Large Cinema,Multiple-function Hall,Auditorium,Hotel,Large Stage,Conference Room,Exhibition Center,Army System etc.

Fabrics are available on our Large Electric Screen

» Fiberglass Matte

» Quality Matte White

» 3D sliver

» Flexible Rear Projection Fabric

» Flexible Matte White

Silent Tubular Motor

Super silent tubular motor is popular for higher quality projection screens and roller blinds, bringing private and quiet quality living environment.

Large Event Motorized Tab-Tensioned Screen with Heavy-duty Tubular Motor designed for Large-scale Presentations
