Light Weight Water Well Drilling Pipe Down The Hole Drill Pipe 50mm - 194mm
Light Weight Water Well Drilling Pipe Down The Hole Drill Pipe 50mm - 194mm
Light Weight Water Well Drilling Pipe Down The Hole Drill Pipe 50mm - 194mm
Light Weight Water Well Drilling Pipe Down The Hole Drill Pipe 50mm - 194mm
Specifications
Brand Name :
Jincheng Drilling Tools
Model Number :
Length 60,76,89,102,114,127
Certification :
ISO9001,CE
Place of Origin :
China(mainland)
MOQ :
3pcs
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000000pcs/year
Delivery Time :
3-15days
Packaging Details :
Iron shelf
Product Name :
Drill Rod
length :
as required
sample order :
support
Thickness :
Customized
package :
iron shelf
Machine Type :
Drilling Tools
Description

Light Weight Water Well Drilling Pipe Down The Hole Drill Pipe 50mm - 194mm

Description

JCDRILL provides drill pipe in every weight, grade and size from 2-3/8” to 7-5/8”.
Our drill pipe goes through vigorous quality checks to ensure each piece meets strict quality standards for superior durability and performance. Each piece of drill pipe is machined from a specific alloy that allows for exceptionally tight dimensional tolerances and enhanced performance.
JCDRILL uses a minimum of 95% nominal wall thickness on new drill pipe. All of our tool joints exceed API requirements and all threading is performed in accordance with API Spec 7-2. Tool joint markings are applied to API RP7G specifications or to meet customer requirements.

If you need, please contact us freely.

Application

Light Weight Water Well Drilling Pipe Down The Hole Drill Pipe 50mm - 194mm

Light Weight Water Well Drilling Pipe Down The Hole Drill Pipe 50mm - 194mm

Technical Parameters of DTH Drill Pipe (Outer Flat Drill Rod):

Diameter Length Wrench Flats Threads
50-194mm 500-10700mm 40,57,65,75,83,95mm F42×10 F48×10 2 3/8''API REG 2 7/8''API REG 3 1/2''API REG 2 3/8''API IF 3 1/2”BECO 4”BECO 4 1/2”BECO 5 1/4”BECO

Rod dia(mm) Rod Length(mm) Thickness (mm) Connect Thread Trigger Slot
inch mm
3 76 1000-6000 5 API2 3/8”REG 57/64.5
3 76 1000-9000 8 API2 3/8”REG 57/64.5
3 1/2 89 1000-6000 6 API2 3/8”REG 70/64
3 1/2 89 1000-9600 8 API2 3/8”REG 70/64

Rod dia(mm) Rod Length(mm) Thickness (mm) Connect Thread Trigger Slot
inch mm
4 102 1000-9000 10 API2 3/7”REG 76/89
4 1/2 114 1500-7620 6 API3 1/2”REG 89/95
4 1/2 114 1500-9140 8 API3 1/2”REG 89/95
4 1/2 114 1500-9140 10 API3 1/2”REG 89/95
4 1/2 114 1500-9140 18 API3 1/2”REG 89/95

Rod dia(mm) Rod Length(mm) Thickness (mm) Connect Thread Trigger Slot
inch mm
5 127 1500-9500 12 API3 1/2”REG 89
5 127 1500-9500 14 API3 1/2”REG 89
5 127 1500-9500 18 API3 1/2”REG 89
5 1/2 140 1500-9500 9 API4 1/2”REG or 4’FH 114
5 1/2 140 1500-9500 10 API4 1/2”REG or 4’FH 114
5 1/2 140 1500-9500 12 API4 1/2”REG or 4’FH 114

Factory

Light Weight Water Well Drilling Pipe Down The Hole Drill Pipe 50mm - 194mm

Delivery
Light Weight Water Well Drilling Pipe Down The Hole Drill Pipe 50mm - 194mm
Light Weight Water Well Drilling Pipe Down The Hole Drill Pipe 50mm - 194mm

Our Services

1. OEM & ODM , as your request .

2. Best quality control : we have our own experienced QC team and the third party test .

3. Quick response .

4. Quick delivery .

5. Best after sevice .
