TIMKEN tapered roller bearing 438-432d double cup with oil holes and groove
TIMKEN tapered roller bearing 438-432d double cup with oil holes and groove
TIMKEN tapered roller bearing 438-432d double cup with oil holes and groove
TIMKEN tapered roller bearing 438-432d double cup with oil holes and groove
TIMKEN tapered roller bearing 438-432d double cup with oil holes and groove
TIMKEN tapered roller bearing 438-432d double cup with oil holes and groove
Specifications
Brand Name :
TIMKEN
Model Number :
438-432D
MOQ :
1 PCS
Price :
USD0.01-50 /PCS
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
10000 PCS/MONTH
Delivery Time :
3-15 days
Packaging Details :
Single Box
Inside diameter :
44.45 mm
Outside diameter :
95.25 mm
Thickness :
61.915 mm
Weight :
2 kg
Category :
Double row inch taper roller bearings
Description

438-432D TIMKEN Double Row outer ring Tapered roller bearing

438-432D Bearing has Double Row Outer Ring with oil holes and groove , cup number is 432D, has two inner rings , cone number is 438 .

The details of 438-432D TIMKEN Double Row outer ring Tapered roller bearing as below :

Specifications

Series

 435

Cone Part Number

 438

Cup Part Number

 432D

Design Units

 Imperial

Bearing Weight

 4.37 lb1.984 Kg

Cage Type

 Stamped Steel

Ab - Cage-Cone Frontface Clearance

 0.05 in1.3 mm

Dimensions

d - Bore

 1.7500 in44.450 mm

D - Cup Outer Diameter

 3.7500 in95.250 mm

B - Cone Width

 1.1772 in29.901 mm

C - Double Cup Width

 2.0000 in50.800 mm

T - Bearing Width across Cones

 2.4376 in61.915 mm

Abutment and Fillet Dimensions

R - Cone Backface "To Clear" Radius1 0.14 in3.600 mm
r - Cup Frontface "To Clear" Radius2 0.03 in0.8 mm

db - Cone Backface Backing Diameter

 2.24 in56.90 mm

Da - Cup Frontface Backing Diameter

 3.46 in87.12 mm

Aa - Cage-Cone Backface Clearance

 0.04 in1 mm

Basic Load Ratings

C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)3 7400 lbf32900 N
C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)4 49700 lbf221000 N
C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)5 12900 lbf57300 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)6 3600 lbf16000 N

<span class="ui-icon ui-icon-minus" style="display:block;text-indent:-99999px;overflow:hidden;background-repeat:no-repeat;width:16px;height:16px;background-image:url(" background-position:-48px="" -128px;position:static;margin-top:-2px;float:right;"="">Factors

K - Factor7 2.05
e - ISO Factor8 0.59
Y1 - ISO Factor9 1.141.70
Y2 - ISO Factor10 1.7
Cg - Geometry Factor11 0.0805

TIMKEN tapered roller bearing 438-432d double cup with oil holes and groove

TIMKEN tapered roller bearing 438-432d double cup with oil holes and groove

TIMKEN tapered roller bearing 438-432d double cup with oil holes and groove
