30216 single row taper roller bearing with 80mm*140mm*28.75mm
30216 single row taper roller bearing with 80mm*140mm*28.75mm
30216 single row taper roller bearing with 80mm*140mm*28.75mm
30216 single row taper roller bearing with 80mm*140mm*28.75mm
30216 single row taper roller bearing with 80mm*140mm*28.75mm
30216 single row taper roller bearing with 80mm*140mm*28.75mm
Specifications
Place of Origin :
China
Brand Name :
HOJE or OEM
Certification :
ISO 9001:2008
Model Number :
30216
MOQ :
10 pcs
Price :
3.1$
Packaging Details :
single box
Delivery Time :
7-15 days
Payment Terms :
T/T, L/C,D/P,Western Union,Paypal,Money Gram,etc
Supply Ability :
100000 pcs/month
Description
Taper Roller Bearing 30216

30216 single row taper roller bearing with 80mm*140mm*28.75mm

  1. This bearing is sold as an assembly only.
Attributes Values
Units mm
Bearing Type single row assembly
Bore Dia (d) 80.0000
Outer Dia (D) 140.0000
Width (B) 28.2500
Outer Width (Bo) 22.0000
Inner Width (Bi) 26.0000
Radius (min) (rs) 2.000
Dynamic Load Rating (Cr) 160,000
Static Load Rating (Cor) 213,000
Max Speed (Grease) 2,400
Max Speed (Oil) 3,400
Max. Shaft Shoulder Dia. Inner (Li) 91.0
Min. Housing Shoulder Dia., Outer (Lo) 124.0
Radius (min) (rs1) 2.500
Weight (g) 1,670.00
Material 52100 chrome steel or equiavelent
