Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery
Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery
Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery
Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery
Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery
Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery
Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery
Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery
Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery
Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery
Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery
Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery
Specifications
Condition :
New
Applicable Industries :
Other
Showroom Location :
Canada, Turkey, Viet Nam, Brazil, Peru, Saudi Arabia, Indonesia, India, Mexico, Russia, Thailand, South Korea, Chile, UAE, Malaysia
Place of Origin :
Henan, China
Brand Name :
Recycle
Model Number :
RSK-CJ200
Type :
PCB Dismantling Machine
Warranty :
1 Year, 1 Year
Production Capacity :
200KG/H
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Marketing Type :
Ordinary Product
Warranty of core components :
1 Year
Core Components :
Motor, PLC, Other
Weight (KG) :
450 kg
Name :
Waste Electronic Recycling Line Production Line
Application :
PCB Components Dismantling
Keywords :
Scrap Tv Board Dismantling System
Certification :
CE Certificate
Capacity :
200-1000 Kg/h
Advantage :
Environmentally Friendly
Final product :
Bare Boards and Components
Delivery time :
As Customer's Demand
Raw material :
E waste Boards,Computer Boards etc
Packaging Details :
Packed in Wooden Case or Container for Waste Electronic Recycling Line Production Line
Port :
Qingdao Port ,Guangzhou Port or Other
Supply Ability :
100 Set/Sets per Month Scrap Electronic Board Grinding System
Price :
$5,000.00 - $33,000.00/sets
Description
Waste Electronic Recycling Line Production Line
Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery
PCB Components Dismantling Machine is used to remove the electronic components on different PCB boards, The drumer made of 6mm thickness #45 steel and its own special technology, which have the characteristics of high temperature resistance, abrasion resistance, safety and reliable, stable performance, high precision, durability. It is Pre Processing before E waste Pcb Recycling Line
Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery

Working Principle
Use the nature gas as the heat, the tin will loose when the temperature arrive at 200-300C. These electronic components will be separated because of scraping function between the circuit board when the rotary drum works. So we can dismantle electronic components from PCB mother board. If our customer want to classify them clearly, then we can equipped with electronic components
screen and magnetic machine.

Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery
The Whole Process:

Dismantling Machine Body—Electronic Component Screen —Magnetic Separator

1. PCB Dismantling Machine Body: Dismantle the electronic component from mother board, As for the tin, we also can recycle it;

2. Electronic Component Screen: Classify the similar size electronic components in one side;

3. Magnetic Separator: Further classify these components which include iron or not.


Technical Parameters
Model
Power (Kw)
Weight (Kg)
Capacity (Kg/H)
Dimension (m)
RSK-200
0.75+1.1+3
450
200
1.67*0.97*1.4
RSK-300
0.75+2.2+3
700
300
1.85*1.2*1.52
RSK-500
0.75+3+3
1100
500
2.1*1.27*1.74
NOTE:

Working voltage:380±10V(415V ,440V also can be customized)

(The Price depends on your capacity and configuration of the machinery;)

Features
Mother board and components can be proceed respectively in the next step to improve economic benefits.

1. Full automatic working, save labor, 1-2 persons are enough;

2. Tin remove and dismantling components at one step;

3. Automatic temperature control system,controlled by PLC;

5. Large capacity: 500kg/h;

6. Operating safety and easily;

7. It can ensure the nature of electronic component and keeps its high recycle value;

8. Friendly to the air environment, all the smoke processing by the waste gas treatment system.

Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery
Related Equipment
When recovering waste PCB circuit board with components ,the first process need to be done is to heat and remove electronic elements which would produce a lot exhaust gases. These gases are harmful,toxic and cancerogenic and will cause secondary pollution without proper treatment before discharge.Heavy metal dust and inorganic acid gases and organic gases were removed separately through our three levels filtrating equipment.

Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery
Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery
Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery
Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery
Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery
Waste Electronic Recycling Line Production Line /E-Waste Recycling Line Machinery
Company Show
As one of the largest E-waste and Other Solid Waste Metal Recycling Machine manufacturer, our factory can provide the whole solutions. Perfect after-sales service is provided and CE certification is provided for all products.
We can dispatch engineers to overseas to help you with installation, training if you need.
Our Company has advanced technology, professional R&D team and perfect sales service system. Besides, we possess several patents and domestically-leading technologies. Our advanced equipment have been currently exported to USA, Spain, Turkey, Italy, Vietnam,Hungary, Australia, Korea, Malaysia, Singapore, India, Philippines, Ireland, Saudi Arabia, Dubai etc.
