Specifications
Type :
Induction Furnace
Certification :
CE
Temperature Control Precision :
±2℃
Vacuum Degree :
6.67*10-2Pa
Power Options :
400kw, 500kw, 600kw
Working Temperature :
Normal Temperature -3000℃
Furnace Atmosphere :
Ar or Vacuum
Measurement Method :
1000-3200℃ use Bi color infrared instrument
Heating Rate :
15℃/min, 10℃/min, 8℃/min
Specification :
Φ800*1600mm, Φ1000*2000mm, Φ1200*2500mm
Weight :
2 T
Place of Origin :
Hunan, China
Brand Name :
Jingtan
MOQ :
1
Maximum Temperature :
3000℃
Power :
160 kw
Feeding Mode :
Bottom loading
Core Components :
PLC
Voltage :
380
Description
High Temperature Graphitization Furnace Discharge Bottom
For Metallurgy Powder Cemented Carbide Sintering
High Temperature Graphitization Furnace with Bottom Discharge for Vacuum Sintering of Metallurgy Powder and Cemented Carbide Materials High Temperature Graphitization Furnace with Bottom Discharge for Vacuum Sintering of Metallurgy Powder and Cemented Carbide Materials
Product Description
Bottom discharge graphitization furnace is mainly used for vacuum sintering of special composite materials, cemented carbide, copper tungsten alloy, titanium alloy and other alloy materials.
Key Characteristics
  • Constructed with welded flange and cylinder group, reinforced with various types of steel and steel plate for load-bearing frame
  • Features double butterfly water inter layer structure
  • Furnace bottom lifting mechanism powered by electric speed reducer with synchronous bearing flexible drive
  • Electric screw bracket ensures stable furnace bottom movement to prevent graphite crucible damage
  • Equipped with upper and lower limit switches for safety
  • Operates in automatic or manual mode according to process requirements
  • Precise temperature control with easy operation
Technical Specifications
Parameter Value
Maximum Service Temperature 3000℃
Working Temperature Range Normal Temperature - 3000℃
Heating Rate 15℃/min | 10℃/min | 8℃/min
Temperature Control Precision ±2℃
Measurement Method 1000-3200℃ use Bi color infrared instrument
Vacuum Degree 6.67*10-2Pa
Furnace Atmosphere Ar or Vacuum
Feeding and Discharging Mode Bottom loading
Specification Φ800*1600mm | Φ1000*2000mm | Φ1200*2500mm
Power 400kw | 500kw | 600kw
High Temperature Graphitization Furnace with Bottom Discharge for Vacuum Sintering of Metallurgy Powder and Cemented Carbide Materials
Key Advantages
Advantage 1: Large Product Processing

The lower discharging graphitization furnace is suitable for processing and graphitization of large products, which greatly improves material handling convenience.

High Temperature Graphitization Furnace with Bottom Discharge for Vacuum Sintering of Metallurgy Powder and Cemented Carbide Materials
Advantage 2: High-Temperature Material Treatment

Ideal for high-temperature treatment of materials (sintering, graphitization, purification, etc.) under vacuum or protective atmosphere conditions.

Company Profile
High Temperature Graphitization Furnace with Bottom Discharge for Vacuum Sintering of Metallurgy Powder and Cemented Carbide Materials

Our Company Philosophy: We are not just your supplier, but your partner providing complete thermal treatment furnace solutions. With our strong R&D team and stable supply chain backed by 14+ years of experience, we operate under strict ISO9001:2015 quality management system.

The State Intellectual Property Office of China has granted us multiple patent rights for our innovative furnace technologies.

Our Patents

High Temperature Graphitization Furnace with Bottom Discharge for Vacuum Sintering of Metallurgy Powder and Cemented Carbide Materials High Temperature Graphitization Furnace with Bottom Discharge for Vacuum Sintering of Metallurgy Powder and Cemented Carbide Materials

Customer Photos

High Temperature Graphitization Furnace with Bottom Discharge for Vacuum Sintering of Metallurgy Powder and Cemented Carbide Materials

Our logistics system serves customers worldwide.

High Temperature Graphitization Furnace with Bottom Discharge for Vacuum Sintering of Metallurgy Powder and Cemented Carbide Materials High Temperature Graphitization Furnace with Bottom Discharge for Vacuum Sintering of Metallurgy Powder and Cemented Carbide Materials High Temperature Graphitization Furnace with Bottom Discharge for Vacuum Sintering of Metallurgy Powder and Cemented Carbide Materials
Frequently Asked Questions
Q: Are you a factory or trading company?
A: Yes, we are China's leading high-temperature vacuum furnace manufacturer with 14+ years experience, granted with many patent certifications in the domestic market.
Q: Do you have customization or OEM service?
A: Yes, we have powerful R&D team and high-tech equipment. We can supply both standard models and fully customized furnaces according to client requirements.
Q: What's your advantages?
  • Quick response to enquiries
  • High quality control standards
  • Stable domestic supply chain
  • Timely delivery
  • Excellent after-sales service including on-site installation and debugging by our engineers
