GCE 64S 204.8V 100A Integrated BMS With Casebox Support Controlled Balance For ESS/UPS
GCE 64S 204.8V 100A Integrated BMS With Casebox Support Controlled Balance For ESS/UPS
GCE 64S 204.8V 100A Integrated BMS With Casebox Support Controlled Balance For ESS/UPS
GCE 64S 204.8V 100A Integrated BMS With Casebox Support Controlled Balance For ESS/UPS
GCE 64S 204.8V 100A Integrated BMS With Casebox Support Controlled Balance For ESS/UPS
GCE 64S 204.8V 100A Integrated BMS With Casebox Support Controlled Balance For ESS/UPS
GCE 64S 204.8V 100A Integrated BMS With Casebox Support Controlled Balance For ESS/UPS
GCE 64S 204.8V 100A Integrated BMS With Casebox Support Controlled Balance For ESS/UPS
GCE 64S 204.8V 100A Integrated BMS With Casebox Support Controlled Balance For ESS/UPS
GCE 64S 204.8V 100A Integrated BMS With Casebox Support Controlled Balance For ESS/UPS
GCE 64S 204.8V 100A Integrated BMS With Casebox Support Controlled Balance For ESS/UPS
GCE 64S 204.8V 100A Integrated BMS With Casebox Support Controlled Balance For ESS/UPS
Specifications
Brand Name :
Gce Hv BMS
Model Number :
RBMS08S64S50A
Certification :
GB/T 16935.1 GB/T 17626.2 GB/T 17626.5 CE
Place of Origin :
China
MOQ :
2 Sets
Price :
Negotiable with toby@hngce.com
Payment Terms :
T/T
Supply Ability :
2000 sets in one month
Delivery Time :
15 days after receive the payment
Packaging Details :
670*560*240mm Cartons
Cell Current Accuracy :
Single cell ±20mV
Current Collection :
Hall sensor
Safety Certification :
UL/CE/ROHS
Insulation Detection :
for minimum 300V systems
Cell Balancing Current :
100mA ± 10mA （ when the monomer is 3.50V）
Max Voltage :
233.6 V
Short Circuit Protection :
Yes
Application :
BESS/UPS battery/Solar battery
Parameter Setting :
available
Power Consumption :
≤10W
Cell Balancing Efficiency :
≥99%
Communication Protocol :
CAN, RS485
Communication :
RS485/CAN
Dry Contact :
Optional, Max 2 Roads Of Output Channel
Cell Balancing :
Active/Passive
Description

GCE 64S 204.8V 100A Integrated BMS With Casebox Support Controlled Balance For ESS/UPS

GCE 64S 204.8V 100A Integrated BMS With Casebox Support Controlled Balance For ESS/UPS

GCE 64S 204.8V 100A Integrated BMS With Casebox Support Controlled Balance For ESS/UPS
