Specifications
Brand Name :
GCE
Model Number :
RBMS-HS100A307.2V
Certification :
CE/RoHS/UN38.3/MSDS/UL
Place of Origin :
China
MOQ :
1 set
Price :
negotiable with bruceliu@hngce.com
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
100 sets per month
Delivery Time :
20-35 working days
Packaging Details :
Corrugated Carton, bundles, pallets, wooden box
Battery Type :
Lifepo4
Max Current :
50A or 100A
Max Voltage :
460.8V
Operating Temperature :
-20℃~+60℃
Size :
560mm*360mm*170mm
Application :
energy storage system
Model No. :
RBMS-HS100A307.2V
Compatible Inverters :
ATESS, Deye, Sinexcel, Goodwe, Kehua, Growatt, Megarevo, Sofar, ...
Warranty :
3 years for RBMS and 1 year for BMU/PCBs
Balancing :
Passive OR Active
Description
Origin Source Factory High Voltage Home ESS GCE High Voltage 96S307.2V 100A 30kW White Solar Stackable Storage 15kWh 20kWh 30kWh 35kWh For Home Energy System
Origin Source Factory High Voltage Home ESS GCE High Voltage 96S307.2V 100A 30kw White Solar Stackable Storage 15kwh 20kwh 30kwh 35kwh For Home Energy System
This Stackable RBMS represents an advanced Battery Management System (BMS) solution, meticulously engineered for residential high-voltage battery energy storage applications. Its core design philosophy centers on a distributed, modular architecture that prioritizes ease of installation, configuration, and ongoing maintenance through plug-and-play connectivity. The system is highly adaptable, supporting DC voltage configurations up to 700V, and employs a robust two-tier architecture combining Battery Management Units (BMU) with the main RBMS controller, interfacing seamlessly with the Power Conversion System (PCS) or inverter.
Key Features
Origin Source Factory High Voltage Home ESS GCE High Voltage 96S307.2V 100A 30kw White Solar Stackable Storage 15kwh 20kwh 30kwh 35kwh For Home Energy System
  • Enhanced Safety Design: Multi-layered safety approach featuring dual short-circuit protection with circuit breaker and fuse, plus insulation resistance detection and continuous monitoring
  • Intelligent Management & Monitoring: Sophisticated BMS for real-time system monitoring with complete self-diagnostics and operational status checks displayed on intuitive HMI
  • Modular Scalability: Flexible system configuration and expansion across wide operating voltage range, supporting series connection of battery cells and parallel operation of multiple units
  • Versatile Connectivity: Multiple communication interfaces including RS485, CAN, Ethernet, and dry contact I/O for broad inverter compatibility
  • Data Logging & Control: Large-capacity memory chip with optional SD card support, automatic cycle current control, and simplified parallel system management
Technical Specifications
Basic Parameters
Category Specification
Electrical Ratings Rated Current: 50A or 100A; Operating Voltage: 100V - 700V; Max System Voltage: 460.8V
Battery Compatibility Primary Chemistry: LiFePO4 (LFP); Also compatible with NMC & LTO
Core Management Charge/Discharge Management: Yes; Cell Balancing: Passive Balancing; Temperature Management: Yes
Protection & Safety Short-Circuit Protection: Circuit Breaker (6kA) + Fuse (10kA); Insulation Withstand: 2800VDC; Certifications: CE compliant
Communication BMU Interface: CAN; PCS/Inverter Interface: RS485 / CAN; Monitoring Interface: Ethernet
Physical & Environmental Dimensions: ~560mm x 360mm x 170mm; Weight: ~15kg; Operating Temperature: -20°C to +60°C; Protection Rating: IP20
System Expansion Parallel Configuration: Supports up to 4 units in parallel; String Configuration: 12S to 24S per battery pack
Communication Interfaces
Interface Type Protocol
BMU Communication CAN
PCS/Inverter Communication RS485 / CAN
Monitoring Software Communication Ethernet
Core Functions
Function Capability
Battery Charge/Discharge Management Yes
String Configuration 12s-24s per battery pack
Battery Temperature Management Yes
Balancing Method Passive Balancing
IAP Upgrade Supported
Short Circuit Protection Circuit Breaker (6KA) + Fuse (10KA)
Pre-charge Function Yes
Parallel Circulating Current Control Yes
Events Recording Capacity 5000 events
DC Start Supported (battery power)
Optional Features
Feature Availability
Insulation Monitor Optional
HMI Display 4 inches (inline mount)
Parallel Connection Up to 4 racks in parallel
Dry Contact Outputs Maximum 2 roads
Additional Specifications
Attribute Specification
Color Ivory
Installation Method Tower up and down plug
Wiring Configuration Down in back out
Operating Temperature -20℃ to 60℃
Operating Humidity 5% to 75% RH
National Standards GB/T 16935.1, GB/T 17626.2, GB/T 17626.5
Safety Certification CE Certification Compliant
Applications
Residential energy storage systems are becoming integral components of smart grids. Our Home Energy Storage Systems (HESS) and Solar Energy Storage Systems (SESS) provide essential support for efficient energy utilization. HESS stores excess solar energy or grid electricity during low-cost periods, ensuring stable household electricity consumption while reducing grid dependence and lowering electricity bills.
SESS stores solar energy generated during daylight hours for nighttime use, maximizing the benefits of renewable energy. Both systems offer sustainable, cost-effective energy solutions that seamlessly integrate into modern energy flows as technology continues to evolve.
Packaging & Shipping
Origin Source Factory High Voltage Home ESS GCE High Voltage 96S307.2V 100A 30kw White Solar Stackable Storage 15kwh 20kwh 30kwh 35kwh For Home Energy System
The stackable high-voltage BMS is packaged in custom boxes with foam inserts to ensure safe transportation. Each package includes anti-counterfeiting tape and contains:
  • Stackable high voltage BMS (HV BMS)
  • User Manual
  • Appendix documentation
Boxes are placed in shipping cartons with additional protective materials and shipped via reputable carriers, including FedEx, UPS, or DHL.
Ordering, Support & FAQs
  • Manufacturer: We are a direct manufacturer and welcome visits to our facility
  • Samples: Sample orders are available for quality verification and market evaluation
  • Customization: Limited product adjustments can be accommodated based on order quantity
  • Delivery: Lead time is typically 15-20 working days, dependent on order specifics
  • Warranty: The RBMS unit is covered by a 3-year warranty, with a 1-year warranty for PCB components
  • Quality Assurance: All products undergo stringent quality control processes from component sourcing through final assembly and pre-shipment testing
  • Installation: Designed as a complete solution, the system does not require specialized technical expertise for installation
