3A Active Balancing high voltage bms Battery Management System ESS BMS 112S358.4V 125A HV BMS For UPS ESS HV Lifepo4 Batteries
3A Active Balancing high voltage bms Battery Management System ESS BMS 112S358.4V 125A HV BMS For UPS ESS HV Lifepo4 Batteries
Specifications
Price :
Negotiable with bruceliu@hngce.com， +86 13620097954（whatsapp）
Insulation withstand voltage :
2800VDC ＜1mA 1min
Place of Origin :
China
Dimension :
440mm*178mm*500mm
MOQ :
2 Set
Voltage :
358.4V
Strings :
112S
Packaging Details :
Corrugated Carton, bundles, pallets, wooden box
Parallel connection :
Support up to 15 BMS connected in parallel
Communication Protocol :
CAN
Style :
Slave and master all in one device
Balancing Method :
3A Active Balancing
Parameter Setting :
available
Brand Name :
GCE
Model Number :
RBMS-S20-125A-358.4V
Certification :
CE/ROHS/MSDS
Display :
3.5-inch
Color :
Black or White Optional
System protection parameter setting :
Support
Operating ambient temperature :
-20℃~60℃
Features :
DC&AC dual power supply
Payment Terms :
FOB/CFR/EXW
Delivery Time :
15-20 days
Current :
125A
Mounting Type :
19" Rack
Compatible inverter :
Deye, Growatt, Goodwe, Sofar, Atess, Sungrow, Bluesun...
Structure :
3-level structure
Supply Ability :
5000pcs / month
Description
3A Active Balancing High Voltage BMS Battery Management System
112S358.4V 125A HV BMS for UPS ESS HV LiFePO4 Batteries
Company Overview
3A Active Balancing high voltage bms Battery Management System ESS BMS 112S358.4V 125A HV BMS For UPS ESS HV Lifepo4 Batteries
Dedicated for more than a decade to the R&D and production of high-voltage battery management systems, GCE Technology serves as a professional OEM/ODM manufacturer offering fully customizable BMS solutions. Our product range supports operating voltages from 96V up to 1500V and is compatible with LFP, NMC, and LTO battery chemistries, catering to diverse needs including residential storage, commercial & industrial ESS, off-grid solar systems, and critical UPS backup power.
Technical Specifications
Parameter Value
Nominal Load Current 125 Amps
System Voltage Options 358.4V, 409.6V, 512V, 563.2V (350V & 750V available on request)
Idle Power Consumption <15W
Voltage Measurement Accuracy ±1% of full scale
Dielectric Strength 2800VDC isolation, leakage current <1mA
Protection Rating IP20 (indoor use)
Dimensions 482×132×500 mm
Net Weight 16 kg
Communication Protocols CAN bus, RS485, Ethernet
3A Active Balancing high voltage bms Battery Management System ESS BMS 112S358.4V 125A HV BMS For UPS ESS HV Lifepo4 Batteries
Core Features
Standard Functions
  • Smart charge/discharge control algorithms
  • Multiple temperature sensing points
  • Over-the-air IAP firmware updates
  • Short-circuit protection
  • Built-in precharge circuitry
  • Parallel operation sync for multiple units
  • Event logging - stores up to 5,000 fault/operation records
  • Redundant dual power inputs for enhanced reliability
Optional Upgrades
  • Integrated insulation monitoring module
  • Local HMI touch panel
  • Cascade expansion - up to 15 units in parallel
  • Dry contact terminals for external equipment control
3A Active Balancing high voltage bms Battery Management System ESS BMS 112S358.4V 125A HV BMS For UPS ESS HV Lifepo4 Batteries 3A Active Balancing high voltage bms Battery Management System ESS BMS 112S358.4V 125A HV BMS For UPS ESS HV Lifepo4 Batteries 3A Active Balancing high voltage bms Battery Management System ESS BMS 112S358.4V 125A HV BMS For UPS ESS HV Lifepo4 Batteries 3A Active Balancing high voltage bms Battery Management System ESS BMS 112S358.4V 125A HV BMS For UPS ESS HV Lifepo4 Batteries 3A Active Balancing high voltage bms Battery Management System ESS BMS 112S358.4V 125A HV BMS For UPS ESS HV Lifepo4 Batteries
Application Scenarios
  • Renewable energy storage: grid-connected PV plants, standalone wind-solar hybrid off-grid systems
  • Mission-critical UPS: data center IDC rooms, telecom base stations, essential facility backup
  • Industrial applications: factory energy backup, mining power storage, isolated microgrids
  • Distributed storage: commercial behind-the-meter, residential on/off-grid battery systems
  • Utility-scale storage: grid peak shaving, frequency regulation, renewable integration support
Business Information
Item Details
Production Nature In-house manufacturing with proprietary R&D team
Sample Policy Evaluation samples available for performance testing
Cell Compatibility Fully supports LFP, NMC, and LTO lithium types
Production Lead Time 15-20 working days after deposit
Payment Terms T/T deposit, flexible arrangements for long-term partners
Warranty 3 years on main RBMS assembly, 1 year on BMU and PCBs
Custom Services Full OEM and ODM capabilities
Quality Control 100% incoming component inspection and finished product testing
Flexible Configurations Adjustable voltage (96V-864V) and current (50A-500A)
Inverter Pairing Standard CAN/RS485 protocols compatible with major global inverter brands
Company Profile
3A Active Balancing high voltage bms Battery Management System ESS BMS 112S358.4V 125A HV BMS For UPS ESS HV Lifepo4 Batteries
Based in China, GCE Technology has concentrated exclusively on high-voltage lithium BMS design and manufacturing for the past ten years. Our modular BMS solutions provide dependable cross-brand inverter compatibility and flexible adaptation to various lithium battery chemistries. Continuous product refinement and rigorous quality assurance have established our long-standing reputation as a reliable supply partner for energy storage distributors and system integrators worldwide.
