Specifications
Brand Name :
AFS
Model Number :
300kg/h line
Certification :
CE
Place of Origin :
China
MOQ :
1set
Price :
$8000-10000/set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000sets/m
Delivery Time :
10-15days
Packaging Details :
non fumigation export standard wooden case
Material :
stainless steel 201
Air compressor :
match 22kw
Capacity :
200-300kg/h
Garlic :
need dry, not suitable for fresh garlic peel skin
Shipping :
EXW,FOB,CNF,CIF
Warranty :
One year
Description

Small Garlic Peeling Line 200-300kg/H, Garlic Skin Peeling Machine, Garlic Processing Machines

Small Garlic Peeling Line 200-300kg/H, Garlic Skin Peeling Machine, Garlic Processing Machines

Garlic peeling process :
garlic elevator---garlic bulb into cloves machine---garlic elevator---garlic peeling machine---garlic picking conveyor

The garlic peeling machine connect with air compressor, to remove the garlic skin, no damage to garlic, high quality. Material use Stainless steel 201.

The peeling machine suitable for dry garlics.

Specification:

Machine name Specification

Garlic elevator

Voltage:380v,50hz

Power:0.55kw

Dimension:2000*500*1550mm

Weight:180kg

Speed : fixed

Garlic bulb into cloves machine

Voltage: 380v,50hz

Power:1.87kw

Dimension:1260*600*1180mm

Weight :138kg

Garlic elevator

Voltage:380v,50hz

Power:0.55kw

Dimension:2000*500*1550mm

Weight:180kg

Speed : fixed

Garlic peeling machine

Capacity:200-300kg/h

Input voltage:380v,50hz

Total power:1.1kw

Air compressor :22kw screw air compressor

air pressure:8kg/cm3

Dimension :1500*630*1370mm

Weight :240kg

Air compressor

22kw,match with garlic peeling machine

Dimension : 1100*800*1300mm

Weight :300kg

Air storage tank : 2070*830*920mm

Weight :180kg

Garlic picking conveyor

The picking conveyor mainly used to pick up garlics that didn’t peeled, then can put into peeling machine and peel again.

Voltage:220v,50hz

Power:90w

Dimension:3000*585*600mm

Weight:90kg
