Inline High-speed Real-time Inspection Series/YS-8500 For SMT Production Line
Inline High-speed Real-time Inspection Series/YS-8500 For SMT Production Line
Specifications
Brand Name :
YUSH
Model Number :
ys-8500
Certification :
CE, RUV Rheinland (China), GMC(GlobalMarket),ISO9001-2000
Place of Origin :
China
MOQ :
1
Price :
USD25000
Payment Terms :
L/C,D/A,D/P,T/T
Supply Ability :
100SETS
Delivery Time :
8
Packaging Details :
woodencase
×-Ray Tube Type :
Open Microfocus Transmitted Ray Source
Tube Voltage Range :
25-160KV
Tube Current Range :
0.01mA~ 1.0mA
Maximum Tube Power :
64W
MaximumTarget Power :
10W
Description

Inline High-speed Real-time Inspection Series/YS-8500 For SMT Production Line

Application Advantages
◆ With planar CT function(PCT),it can be applied to 3D/CT inspection of printed circuit boards,SMT,IGBT,wafers,etc.
◆ With cone beam CT function,it can be applied to the inspection of sensors,relays,micro motors,materials, and aluminum castings
◆ Convenient 360°fixed-point observation mode
◆ 2D void inspection software module(optional)
◆3D measurement and analysis software module(optional)
Application Fields
◆ Soldering quality inspection of solder joints on PCB,BGA components,integrated circuits(IC)and their bond wires inspecton,semiconductor package inspection and internal connection,electronic power(IGBT)module inspection,Wafer defect inspection(WLCSP)
◆ Inspection of sensors,relays,fuses,coils,micro drive systems and air bag control systems,micro motors (MEMS,MOEMS),cables and plugs,plastic parts, various materials such as plastics,ceramics,biological materials,optical components,small titanium and aluminum castings
360°Rotating Observation Mode
Inline High-speed Real-time Inspection Series/YS-8500 For SMT Production Line
Product Parameters

Model No.

YS-8500

X-

Ray

Tube

×-Ray Tube Type

Open Microfocus Transmitted Ray Source

Tube Voltage Range

25-160KV

Tube Current Range

0.01mA~ 1.0mA

Maximum Tube Power

64W

MaximumTarget Power

10W

Micro Focus Size

<1μm

Flat Panel

Detector

Flat Panel Type

A(O(m)pt(o)io(rp)n(h)a(o)lu)s Silicon Flat Panel Detector

Pixel Matrx

1536x1536

Field of View

130mmx130mm

Resolution

5.8Lp/mm


Frame

Rate(1× 1)

20fps

AD

Conversion Digits

16bits

Equipment

Specifications

Maximum Sample

Size

750mmx650mm

Maximum

Inspection Area

550mmx550mm


Geometric

Magnification

2000X

Input Powe

n

220V 10A 50-60Hz

Operation System

DEL Precision T7920 Image Workstatio

Dimensions

L1600mm×W1700mm×H2000mm

Net Weight

About 2950 KG
arameters
