Pneumatically Driven High Efficiency PCB Depanelizer with Customizable Cutter for SMT Assembly
Pneumatically Driven High Efficiency PCB Depanelizer with Customizable Cutter for SMT Assembly
Specifications
Brand Name :
YUSH
Model Number :
YSV-LT
Place of Origin :
Guangdong
MOQ :
1
Price :
USD1100
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
1000
Delivery Time :
20work days
Model :
YSV-LT
Weight :
5.7kg
Cylinder Stroke (mm) :
10
Description
Advanced PCB depaneling solution designed for SMT assembly lines, offering precision cutting and high efficiency for electronic manufacturing applications.

Pneumatically Driven High Efficiency PCB Depanelizer with Customizable Cutter for SMT Assembly

Key Features
  • Durable upper and lower blades made from special materials for extended service life
  • Minimizes shearing stress to prevent micro-cracks in soldering joints
  • Compatible with complex double-panel structures with customizable cutter thickness for various V-groove widths
  • Quick and convenient cutter replacement system
  • Reliable pneumatic operation with footswitch control for high efficiency
  • Four supporting pins ensure PCB level positioning for improved cutting quality
  • Customizable cutter thickness and height specifications
  • Easy waste collection with accessible waste box design

Pneumatically Driven High Efficiency PCB Depanelizer with Customizable Cutter for SMT Assembly

Technical Specifications
Operating Pressure (bar) 4～6
Cylinder Bore (mm) Φ80
Cylinder Stroke (mm) 10
Cylinder Output (kgf) 181-272
Max. Cutting Thickness (mm) 2.50
Max. Cutting Width (mm) 8
Max. Accessory Height (mm) 25.00
Weight (kg) 5.7
