I.Product Features

• Compact & Adaptable: Designed to meet shipyard technical specifications, including dimensional constraints and lifting lugs. Features a small footprint, easy installation, and high adaptability for marine vessels and offshore platforms.
• User-Friendly: Simple operation and maintenance. Requires only seawater and power supply to produce water after startup.
• High Performance: Achieves stable, reliable operation with a salt rejection rate exceeding 98.5%, effectively removing harmful components such as inorganic salts, heavy metal ions, organic matter, bacteria, and pathogens from seawater.
• Quality Assurance: Produces water that meets China's National Drinking Water Sanitation Standard (GB5749-2006).

II.Product Specifications

III.System Functions

1. Overpressure Protection: Automatically shuts down and triggers audible-visual alarms when high-pressure pump outlet pressure exceeds 6.2 MPa.
2. Low-Pressure Protection: Activates shutdown and alarms when inlet pressure to the high-pressure pump drops below 0.05 MPa due to insufficient pretreatment water supply.
3. Multi-Media Filter Cleaning: Equipped with manual multi-way valves for backwashing when differential pressure reaches 0.1 MPa.
4. RO Membrane Cleaning System: Enables physical, chemical cleaning, and preservation solution injection for membrane modules.
5. Quality Control: Automatically diverts water discharge if product water quality exceeds standards.

IV.Key Components

V.Delivery Package

1. Water Treatment Unit
2. Operation Manual & Video Tutorial
3. Completion Documents:
   • Product certificate
   • Factory test report
   • Packing list
   • Equipment drawings
4. Consumables & Spare Parts

VI.Notes

1. Performance Conditions: Daily output is measured at 25°C inlet temperature, 35,000 mg/L salinity, and 4.5 MPa operating pressure.
2. Customization: Available upon customer request.
