Customizable 7 Stage Reverse Osmosis System Water Treatment Machine Automated
Customizable 7 Stage Reverse Osmosis System Water Treatment Machine Automated
Customizable 7 Stage Reverse Osmosis System Water Treatment Machine Automated
Customizable 7 Stage Reverse Osmosis System Water Treatment Machine Automated
Specifications
Brand Name :
HongJie
Certification :
ISO 14001,ISO 9001,CE,EPA
Place of Origin :
Shenzhen,China
MOQ :
>=1sets
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
>300sets/month
Delivery Time :
1-7working days(depand on raw materials stocking)
Packaging Details :
export standard wooden case
Flow Rate :
0.25~200m³/h (customizable )
Produced Water Quality :
Conductivity < 10μs/cm
Core Technology :
Double-stage Reverse Osmosis (RO)
Key Components :
RO Membrane Modules
Operation Mode :
Full Automatic (PLC-controlled)
After-Sales Service :
2-Year (excluding Consumables)
Filtration accuracy :
RO membrane ：0.0001 - 0.02 micron；PP: 1 - 5 micron
Desalination rate :
99%
Pollutant removal rate :
Residual chlorine removal rate:
Water recovery rate :
50 - 80%
Work pressure :
1 - 1.5MPa
Applicable water temperature :
5 - 45℃(25℃ is best)
Description

I.Overview
This is a device that utilizes reverse osmosis technology to purify water through seven stages of filtration. It effectively removes impurities, heavy metals, bacteria, and other harmful substances from water. It is commonly used for household drinking water purification and industrial water treatment applications

II.Seven-Stage Filtration Components and Functions

Raw Water → PP Sediment Filter → Granular Activated Carbon (GAC) Filter → Compressed Activated Carbon (CAC) Filter → RO Reverse Osmosis Membrane Filter → Post Carbon Filter → Mineralization Layer (Optional) → Ultraviolet Sterilizer (Optional)→ oulet water

PP Sediment Filter Removes large particles (sand, rust, sediment) using polypropylene fibers.
Granular Activated Carbon (GAC) Filter Adsorbs chlorine, odors, and some organics; protects RO membrane.
Compressed Activated Carbon (CAC) Filter Further adsorbs organics, colors, and odors; protects RO membrane.
RO Membrane Filter (Core) Removes ions, bacteria, viruses, and organics (pores: 0.0001 - 0.02 microns).
Post Carbon Filter Improves taste and removes final traces of odor/impurities.
Mineralization Layer (Opt) Adds beneficial minerals and balances pH/taste.
UV Sterilizer (Opt) Kills bacteria and viruses using ultraviolet light

III.Applications
Household drinking water
Bottled water production
Water for pharmaceuticals & electronics
Treats well water, groundwater, borehole salty water, brackish water to required standards.

IV.Here is a guideline for you to get a proper quotation
Tell us the raw water/source of water(tap water, well water, or sea water, etc)
Provide water analysis report(TDS , conductivity, or resistivity, etc)
Required production capacity( 5m³/H, 50m³/H,or 500m³/H, etc)
What's the pure water used for( industrial,Food and Beverage,or agriculture, etc )
