1.44 Cubic Backhoe Bucket Crawler Excavator PC335-10 for Heavy Tracked Digger Machinery
1.44 Cubic Backhoe Bucket Crawler Excavator PC335-10 for Heavy Tracked Digger Machinery
1.44 Cubic Backhoe Bucket Crawler Excavator PC335-10 for Heavy Tracked Digger Machinery
1.44 Cubic Backhoe Bucket Crawler Excavator PC335-10 for Heavy Tracked Digger Machinery
1.44 Cubic Backhoe Bucket Crawler Excavator PC335-10 for Heavy Tracked Digger Machinery
1.44 Cubic Backhoe Bucket Crawler Excavator PC335-10 for Heavy Tracked Digger Machinery
1.44 Cubic Backhoe Bucket Crawler Excavator PC335-10 for Heavy Tracked Digger Machinery
1.44 Cubic Backhoe Bucket Crawler Excavator PC335-10 for Heavy Tracked Digger Machinery
1.44 Cubic Backhoe Bucket Crawler Excavator PC335-10 for Heavy Tracked Digger Machinery
1.44 Cubic Backhoe Bucket Crawler Excavator PC335-10 for Heavy Tracked Digger Machinery
1.44 Cubic Backhoe Bucket Crawler Excavator PC335-10 for Heavy Tracked Digger Machinery
1.44 Cubic Backhoe Bucket Crawler Excavator PC335-10 for Heavy Tracked Digger Machinery
Specifications
Operating Weight :
33 Ton
Place of Origin :
Shandong, China
Brand Name :
komamax
Moving Type :
Crawler Excavator
Bucket capacity :
1.44m³
Maximum Digging Height :
10200mm
Maximum Digging Depth :
6620mm
Machine Weight :
33500 kg
Max Digging Radius :
11100mm
Rated Speed :
5.2/3.3 km/h
Warranty :
1 Year
Hydraulic Cylinder Brand :
komamax
Hydraulic Pump Brand :
komamax
Hydraulic Valve Brand :
komamax
Engine Brand :
komamax
UNIQUE SELLING POINT :
With the cab; side swing; telescopic
Power :
194KW
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
PLC, Pressure vessel, Engine, Gear, Motor, Pump, Bearing, Gearbox
Product name :
tracked bucket Excavator
Rated Power KW/rpm :
194/2200
Gradeability (35°) :
70%
Hydraulic tank capacity :
595
Arm digging force (KN) :
245
Showroom Location :
None
Condition :
New
Marketing Type :
Ordinary Product
Applicable Industries :
Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Retail, Construction works , Excavator
Price :
$88,000.00/sets 1-9 sets
MOQ :
1 set
Description
Company Profile
1.44 Cubic Backhoe Bucket Crawler Excavator PC335-10 for Heavy Tracked Digger Machinery

About Company
As a large-scale producer for excavator and bulldozer, we have a comprehensive brand and a wide range of models, which can provide
you with the most favorable price.
I look forward to answering your questions about new or used cars.
Click "Query" to get in touch with us!
Products Description
1.44 Cubic Backhoe Bucket Crawler Excavator PC335-10 for Heavy Tracked Digger Machinery
1.44 Cubic Backhoe Bucket Crawler Excavator PC335-10 for Heavy Tracked Digger Machinery
1.44 Cubic Backhoe Bucket Crawler Excavator PC335-10 for Heavy Tracked Digger Machinery
1.44 Cubic Backhoe Bucket Crawler Excavator PC335-10 for Heavy Tracked Digger Machinery

Click here for more details
1.44 Cubic Backhoe Bucket Crawler Excavator PC335-10 for Heavy Tracked Digger Machinery
1.44 Cubic Backhoe Bucket Crawler Excavator PC335-10 for Heavy Tracked Digger Machinery
Exhibition
Product Paramenters








Basic parameters of the whole machine
Overall length mm
11080
Overall width mm
3190
Transport height mm
3280
Overall width of upperstructure mm
Overall height of cab mm
3280
Shoe width mm
600
Track gauge mm
2590
Min. ground clearance mm
495
Tail swing radius mm
3420
Track ground length mm
4030
Track length mm
4955





Working Range
Max. digging height mm
10200
Max. dumping height mm
7135
Max. digging depth mm
7370
Max. vertical wall digging depth mm
6380
Max. digging reach mm
11100
Min. swing radius mm
4265


Dynamical system
Cylinders
6X125X140
Displacement
8.3
power
194kw/2200rpm
Cooling method
In the cold


Hydraulic System
Operating Pressure
37MPa
Maximumflow L/MIN
2X330
Pump
K3V180DT




performance parameter
（SAE）Bucket Capacity
1.7
Climbing ability
70%（35°）
Maximum digging force
245KN
Travel speed
5.2/3.3
Unit swing speed
8.5r/min
Hydraulic tank capacity
595
